I did some continuity tracing on my circuit board and found that pin 14, listed as NRST on the ST datasheet, goes under the MCU through two vias and ends up at pin 30 on M1. This corresponds with the uC Board pdf.
There is continuity between these points and both present 3.3v when it's powered up. I see no other connections to them so I'm at a loss how this is possible unless there is a fault under or in the chip. NRST is an external reset and is not generated internally right? There is no continuity between pin 14 and adjacent pins or pin 30 on M1 and adjacent pins.
The NRST pins on P1, P2, P6, P9 and P14 have continuity with the 14th pin along bottom of MCU which is listed as PE8 or pin 39. These also present 3.3v when powered up.
With pin 14 set high, it's in reset mode and I won't be able to connect with it I'm guessing. Should I try lifting pin 14 off the trace and test voltage again? That way I'd no if it's internal or external.
There is continuity between these points and both present 3.3v when it's powered up. I see no other connections to them so I'm at a loss how this is possible unless there is a fault under or in the chip. NRST is an external reset and is not generated internally right? There is no continuity between pin 14 and adjacent pins or pin 30 on M1 and adjacent pins.
The NRST pins on P1, P2, P6, P9 and P14 have continuity with the 14th pin along bottom of MCU which is listed as PE8 or pin 39. These also present 3.3v when powered up.
With pin 14 set high, it's in reset mode and I won't be able to connect with it I'm guessing. Should I try lifting pin 14 off the trace and test voltage again? That way I'd no if it's internal or external.
NRST is pulled up and must be kept this way.
NRST is not external reset per-say... is tied to the reset trigger of the uC.
if you pulse the line low the uC reset itself. but for correct operation this line must be kept at uC-vdd potential.
Beside the clock, i would check each and every line connected to the uC "on-pin" (with very sharp multimeter probes).
Check where the uC leg enter the silicon/plastic body rather than the pads where the pin is supposed to be soldered on. While doing that, try to use the lowest amount of force with probe-tip to not make contact on an eventual faulty connection and give a false-positive results.
my 2c
NRST is not external reset per-say... is tied to the reset trigger of the uC.
if you pulse the line low the uC reset itself. but for correct operation this line must be kept at uC-vdd potential.
Beside the clock, i would check each and every line connected to the uC "on-pin" (with very sharp multimeter probes).
Check where the uC leg enter the silicon/plastic body rather than the pads where the pin is supposed to be soldered on. While doing that, try to use the lowest amount of force with probe-tip to not make contact on an eventual faulty connection and give a false-positive results.
my 2c
