Yes. I have this diagram. It shows three switches. Mine only has 2. The 33 button is the one wired directly to the power board. it has no wires connected to the pot. I'll add a picture later today.
There are only two switches in this diagram. Power is the SPST on-off, this breaks or connects the incoming AC.
Speed select is the SPDT on-on, this chooses 33 or 45 rpm.
Speed select is the SPDT on-on, this chooses 33 or 45 rpm.
That's interesting. In your upskirt shot in this thread, that photo shows three switches. Why would that have three then?
Honestly I was thinking the same thing… and I don’t have the table anymore so can’t take a look and see if I can figure it out.
Can you take some photos of yours?
Can you take some photos of yours?
Sure. I'll send a few over. They might not be as good as yours but I'll see how they turn out. It will probably be later tonight. Also, do you happen to have any kind of testing procedure for the various components and what the readings should be? Like what it the output voltage on the POTS, the switch itself, etc.
6L6: I didn't get to posting the photos last night. Here are the ones I took. Also, I did some testing on the voltages. Here is what I got:
Power Leads from the plug to the power board: 120V
With 33 speed selector pushed down: 120v across the 2 white wires at the switch and of course on the power board also.
The 33 speed Pots: DC current voltage of 36v (Not sure if AC voltage is correct for a Pots or not. So I took a DC voltage reading)
Power to the Strobe Light is 15.6v but is doesn't light up.
The 45 Pots: 0 V
Power Leads from the plug to the power board: 120V
With 33 speed selector pushed down: 120v across the 2 white wires at the switch and of course on the power board also.
The 33 speed Pots: DC current voltage of 36v (Not sure if AC voltage is correct for a Pots or not. So I took a DC voltage reading)
Power to the Strobe Light is 15.6v but is doesn't light up.
The 45 Pots: 0 V
