Thanks Ed for the early Christmas present :). Not pictured are enough caps, resistors, diodes and transistors to populate these boards twice over :D. Now to get on building!!

The large PCB has most of the passive components, the rest of what you should need are in the bag. The schematic of the amplifier is the same as the one in the box. The rails can be a bit higher voltage as the output transistors are bigger as are the heatsinks. There is also a DC servo on the card but it should be fully populated. Adequate power transformers were provided.

The smallest hold flat pack transformers as marked. The matched set are for a DC powered audio amplifier. It has two amplifiers bridged to provide an output without an output capacitor. It should have a differential input pair followed by a voltage gain stage feeding a driver transistor attached to the output stage. The second amplifier takes it's input from the output of the first amplifier as both stages invert. It was designed with many output transistors to require minimal heat sinking. Each output transistor only used a small individual unit.

I don't have a schematic for these any more. You can use it as a normal amplifier with little modification. Just cut a few traces.

The basic design was first used in the Citation 12.

Last edited:
The large PCB has most of the passive components, the rest of what you should need are in the bag. The schematic of the amplifier is the same as the one in the box. The rails can be a bit higher voltage as the output transistors are bigger as are the heatsinks. There is also a DC servo on the card but it should be fully populated. Adequate power transformers were provided.

The smallest hold flat pack transformers as marked. The matched set are for a DC powered audio amplifier. It has two amplifiers bridged to provide an output without an output capacitor. It should have a differential input pair followed by a voltage gain stage feeding a driver transistor attached to the output stage. The second amplifier takes it's input from the output of the first amplifier as both stages invert. It was designed with many output transistors to require minimal heat sinking. Each output transistor only used a small individual unit.

I don't have a schematic for these any more. You can use it as a normal amplifier with little modification. Just cut a few traces.

The basic design was first used in the Citation 12.

Great! thanks Ed!!

Having looked again, it appears the smaller amplifier card is a bridged amplifier, but does not have the differential input stage used by most amplifiers. To make tracing a bit more difficult the card was designed using tape and dots, so TO-92 transistors don't quite stand out. But I assure you, there is knowledge to be learned from tracing out the circuit!
