Hi,
Congratulations to all team of administration with successful forum upgrade!
Here are pictures of my latest DIY Project – gainclone the „G”:
Back panel
Inside (diy heatsink from two old ones )
Ready for testing
During tests side by side with Leach SS
quick specs:
Two transformers 2x24VAC 100W (on caps - 34VDC);
Two bridges from 16 MUR820 ;
Four RIFA low ESR 15 000uf 40V;
p2p wiring;
LM3875TF non inverting circuit with zobel network (0,1uf + 10R);
Case from eBay;
diy 4mm aluminium chassis;
2 apem white 230V LED (flat type);
Key switch (mechanical child lock );
Two silver G letters with Swarovski crystal
Amp sounds really nice and powerful in whole range (very detailed High and Mid range, also low end is good)-no doubt, but I still prefer my SS leach (of course is in different weight class )
I will try to measure amp parameters later.
So, next will be some tube project i hope...
Congratulations to all team of administration with successful forum upgrade!
Here are pictures of my latest DIY Project – gainclone the „G”:

Back panel

Inside (diy heatsink from two old ones )

Ready for testing

During tests side by side with Leach SS
quick specs:
Two transformers 2x24VAC 100W (on caps - 34VDC);
Two bridges from 16 MUR820 ;
Four RIFA low ESR 15 000uf 40V;
p2p wiring;
LM3875TF non inverting circuit with zobel network (0,1uf + 10R);
Case from eBay;
diy 4mm aluminium chassis;
2 apem white 230V LED (flat type);
Key switch (mechanical child lock );
Two silver G letters with Swarovski crystal
Amp sounds really nice and powerful in whole range (very detailed High and Mid range, also low end is good)-no doubt, but I still prefer my SS leach (of course is in different weight class )
I will try to measure amp parameters later.
So, next will be some tube project i hope...
osscar where did you get the led setup for the front panel ?
are they running off the mains ?
are they running off the mains ?
http://www.apemswitches.be/1-26847-Serie-details.php?id=80
Yes - AC 230V, parallel with primary windings.
here is closer look on front panel:
Yes - AC 230V, parallel with primary windings.
here is closer look on front panel:

Last edited:
Here is my first ever DIY audio creation. PD LM3875 gainclone 😀
Well done, I like it!..
Are you using it for Headphone amp?
Because if you do.That is a lot power for it lol

headphone jack is just for show atm 🙂 Managed to fail at planning that one quite right. It's just filling in the hole now while I figure out how to implement it. Just plan on running headphones occasionally.
headphone jack is just for show atm 🙂 Managed to fail at planning that one quite right. It's just filling in the hole now while I figure out how to implement it. Just plan on running headphones occasionally.
Well you can use a toggle switch for on/off
Here is my baby, finally deemed worthy of going on the Gallery thread. I just put the lid on it yesterday, for hopefuly the final time.

It shows the guts of the thing, mostly. I need to take one final pic of it, showing it sealed and turned on - all black, with an ultra-bright single white led on the front.
As you can notice, it's based on the chipamp.com boards, dual-mono design with 120VA transformers per channel. It's serious overkill, but the price was the same as the 80VA I wanted to use so .. why not. It runs on 35V rails, which gives it enough power to blast the glass off my windows, when plugged into the Cerwin Vega speakers.
In the back you can see an IC-based speaker protection circuit, that works perfectly well, as well as a ground-loop disconnecting network.
The sound? Well .. as far as I can judge it - this thing sounds wonderful. I don't know how to compare it to my NAD amp, but it's at least as good, maybe more dynamic somehow. Unlike my NAD, however, I can put it in my backpack and take it anywhere 🙂 It's the size of a netbook, although a liiiitle heavier.
Many thanks to all of you that have helped me with it.

It shows the guts of the thing, mostly. I need to take one final pic of it, showing it sealed and turned on - all black, with an ultra-bright single white led on the front.
As you can notice, it's based on the chipamp.com boards, dual-mono design with 120VA transformers per channel. It's serious overkill, but the price was the same as the 80VA I wanted to use so .. why not. It runs on 35V rails, which gives it enough power to blast the glass off my windows, when plugged into the Cerwin Vega speakers.
In the back you can see an IC-based speaker protection circuit, that works perfectly well, as well as a ground-loop disconnecting network.
The sound? Well .. as far as I can judge it - this thing sounds wonderful. I don't know how to compare it to my NAD amp, but it's at least as good, maybe more dynamic somehow. Unlike my NAD, however, I can put it in my backpack and take it anywhere 🙂 It's the size of a netbook, although a liiiitle heavier.
Many thanks to all of you that have helped me with it.
Here is my completed chip amp.
I used an old Sky Digibox chassis.
Thanks to everyone who helped me out with my newbie questions
I used an old Sky Digibox chassis.
An externally hosted image should be here but it was not working when we last tested it.
Thanks to everyone who helped me out with my newbie questions
Last edited:
Thats a pretty cool chassis! I like that it is blank. No retailer mark on it.
I am putting one together now with Sonance Sonamp 260 chassis. Bought it working on ebay and thought it made a nicer case than an amp! 🙂
Perfect inside. Sinks and place to mount a toroid. That toroid gets close to speaker outputs though so maybe some hum. We will see.
Uriah
I am putting one together now with Sonance Sonamp 260 chassis. Bought it working on ebay and thought it made a nicer case than an amp! 🙂
Perfect inside. Sinks and place to mount a toroid. That toroid gets close to speaker outputs though so maybe some hum. We will see.
Uriah
i used filler to cover over all of the wholes and then primed and sprayed it. Ford polar grey and citroen black😱
i used filler to cover over all of the wholes and then primed and sprayed it. Ford polar grey and citroen black😱
Well, whatever you did to it...it looks really nice.congrats!

Atila.
Image link dosent work. Any chance you can re-post the link?
Ah, sorry, I didn't see that the new image tags prevented me from linking to the gallery. Here is the link:
http://picasaweb.google.com/theatilla/Ampy
