I cant find a service manual of this amplifier, but I need to figure out what the bias setting of the amplifier needs to be.

The working channel has about a 1mv drop across the 0.1 ohm resistor, so i adjusted the rebuilt channel to match.

Seems to be working, but I would prefer to know precisely what it is supposed to be.

Pair of Tamura A-8713

Can be used as line output transformers: 20K-600 / 20ma. There are 2 primary and 2 secondary, so multiple combinations possible

Or vice versa as step-up, with e.g. ratio 1:5.6 or 1:11

SOLD

Over the years I've discovered the benefits of chassis vibration dampening when mounting midbass / midrange drivers on most types of baffle surfaces.

The largest benefit I've observed was by fully isolating the driver chassis from the baffle structure using viscoelastic materials as well as other elastomers and polymers. The latest project I'm planning to do this with is on my large 3 ways using the Eminence Canna-bass CB3012-N8 woofer /midbass, Bliesma M74A and T34B.

Some of the lighter weight cast frame drivers can be prone to resonances due to chassis flex. This somehow needs to be supressed when using the driver for more critical hifi applications. You can observe the main effects of these resonances by observing the impedance sweep of the chassis in free air vs clamped in a baffle. The resonances are usually found in the midbass region between 200 - 800 hz in form of smaller impedance peaks. The trick is isolating them from spider resonance and radial cone modes occurring in a similar region.

I purchased some supplies online and from a local hardware store. I chose #10-32 screws with a shallow allen head for the Eminence 10s which fit perfectly in the recessed chassis bolt hole pockets. I'm using 1/4" OD, 3/16" ID flanged grommets (typically used to isolate hoses passing through metal from rubbing). These fit perfectly around the 10-32 screws and locate the driver on the baffle flange. A small washer under the screw head will be needed to keep the underside from, twisting the grommet while tightening the driver down. Of course I'll be using either a strip of neoprene or sorbothane between the chassis and baffle flange. This will fully isoate the chassis from the baffle surface.

Hello everyone,
I have been registered since a long long time ago, I wanted to make a post, but I was asked to introduce myself as a new member to be able to post again.

So I am introducing myself as an electronic hobbyist doing restorations for my pleasure and also by loving those iconic vintage audio gears as an audiophile as well.
I am restoring "as new" those gears such as R2R's, amplifiers, preamps and Loudspeakers.
I have some skills in electronics, but also as a full DIY modeler I am able to work wood, do wood veneer cabinets with High gloss varnished finishing, rebuilding faceplates with graphic illustrating done with computer work by rebuilding original layouts.
*Sharing some pics of some work I have done on those HiFi gears from my collection; I have fully restored and also upgraded these beautiful audio icons...

As I just like the look of the old 807 tubes I decided to build a amplifier based on the 1930s 807 type.
As I recently finished the build I thought I would post the results in case it was of interest.


Is this finest sounding amplifier ever built? No not even close but for the first beam power tube technology of the 1930s it does perform surprisingly well.
Total THD at 1 watt is below 0.05% and at 1Khz and below 0.2% at 40 watts output. At 20Khz THD is below 0.4% at full power and under 0.05% at 30HZ again at full power.
At 1 watt the THD is mostly second harmonic, however it transitions to mostly third harmonic above about 5 watts.

The 807s plates run at 510V into a P-P impedance of 6600 ohms , with fixed bias and regulated screens set to 350V.
The screens are provided with a portion of the plate AC signal voltage in a variation on the classic UL mode of operation.
Running the 807 in UL mode really helped tame some of the 807s bad habits and greatly helped with stability in general.
There are also large ferrite sleeves on each plate lead , 1K screen resistors and 100 ohm grid stoppers.
The 350V on the screens may seem high as the tubes are rated at only 300V but that is in pentode mode.
In triode mode the screen can be run to 400 volts according to some data sheets.
The way I am running the 807 screen the 350V on the screen is modulated by the plate AC voltage and so drops to about 275 volts at minimum plate voltage where
maximum screen current occurs.
This greatly limits the screen power dissipation at full power while still providing good plate current and drops the output tube distortion to about 1/2.

I chose to drive the 807s with a cathode follower for two reasons. First it allow for a low DC impedance on the 807 grids
This stabilizes the bias current in the presence of any grid leakage when the tubes are run hard.
Second it allows a smooth transition into class AB2 at high power instead of clipping and blocking distortion that most class AB1 designs enter at zero grid volts.
This provides extra output power and a fast recovery for any clipping. Class AB2 is entered at about 25 watts output and extends power to 40 watts.

The cathode follower is driven by a LTP pulled to a -120V rail by a high value resistor.
The cathode resistor does not provide the perfect balance of a current source but the small error is easily trimmed out with a POT during amplifier setup.
As a balance adjustment is helpful for correcting output tube gain errors the adjustment is needed anyway.
I stuck with a resistor as it is simple and bullet proof and importantly low in distortion at 20Khz where many current sources have increased THD and loss of impedance do to speed issues within the current source.


The input stage is a simple pentode amplifier using a 6AK5. Nothing fancy here but the 6AK5 can provide a lot of low distortion gain.
The 6AK5 is direct coupled to the LTP to limit phase shift in the amplifier and only one coupling capacitor is used between the LTP and the cathode follower.
The screen is bypassed by a 100nF capacitor to the cathode to increase gain. The capacitor value is chosen to insure low frequency stability by providing a shelving in the low frequency gain. Further LF phase compensation is proved by a large value cathode capacitor, resistor network.
Feedback is injected into the 6AK5 cathode from the 8 ohm speaker tap.
The result is a stable amplifier that is perfectly happy and stable at high and low frequencies with no load on the transformer secondary.

All rails are regulated except the 510V B+ on the 807 plates.
This provides a lot of added margin in the output tubes by stabilizing all voltages and currents and makes the amplifier mostly immune to line voltage variation.
Hum is banished as well.
The cost of regulated rails is complexity, there is no denying it.
Regulated rails are great for performance and stability but exact a price in complexity.

Here are some pictures of the newly finished build.
It is pretty busy inside and there is some wiring cleanup still to go.
I also posted the circuit diagram.

Now there will be a burn in for a few weeks providing background music in my lab.

Thanks to @Mitch311 for suggesting this thread.

Huge thanks to @sheeple for organising the group buy

So, what will you do with your drivers from the group buy?

I intend to try them in my DIY SH50 style MEH horns.

Seen here with BMS4550s



They have to reach down to the 5" mids.
They will be used in a hifi setting and not huge volumes, hopefully they will take it..

I have a pair of BMS 4550 drivers for PA🙂

I'm using my Vitavox S2s at the moment, and have made an easy screw in adapter for fast swap over.

Here with the S2 and full driver compliment



I'm sure more then just me would love to see your builds and uses.
What's planned and what's on the work bench?

Hi,
I've signed up to ask for help in restoring an old Philips CD104 CD player. It's a wonderful device and the construction quality is really very impressive, so it would be a shame to leave it nonfunctional.

That's about it.

Hi,

I have always had a 'thing' for the classic TAD 2402 and now it is time to get started. However, the TD-4001 are either difficult or near impossible to source and even a pair of beat-up TD-4001's are pricey these days.

I have read a few comments about people that have had good results using the JBL 2450 with Truextent diaphragms - is this the way to go if I cannot find a pair of reasonably priced TD-4001's? It seems like it matching the horn pretty nicely in terms of exit angle etc.

Was the original fitted with a gasket between the enclosure and the horn to prevent air leaks and how was the horn held in place?

I will probably have Athos Audio do the horns and probably also the enclosures.

Thanks!

/Jeppe

Hey Guys

So the other day I picked up a used set of Martin Logan Aerius i ESL's in great shape and I have been really enjoying them. I was thinking it might be a good idea to think about replacing the 20+ year old electrolytic caps in the crossovers with something better such as Clarity caps. I'm fairly new to this but know this is popular with conventional style loudspeakers. I'm comfortable working through parts values but I'm not really 100% sure where my time and money would be best spent so I'm here to take in any info offered.

Martin Logan has proved to be extremely helpful and provided me with crossover schematics and a detailed electrical print on the whole speaker. I have not opened these up yet to take a look for myself but plan on doing so this week at some point. I've attached all the electrical info for everyone's viewing pleasure.

Behringer DEQ2496 is well known cheap audio processor, which was on the market for almost 10 years . Now you can find even more impressive devices like made by MiniDSP ot DSPeaker, but they are more expensive too and for some applications are less flexible. DEQ2496 was (and likely still is) considered a best bang for the buck digital processor that packs a lot of goodies - parametric and graphic equalizers, dynamic compressor/expander, dynamic equalizer, limiter, stereo field expander, ADC and DAC with 24/96 sampling. All these features can be used in parallel and stacked on each other. That is why a lot of DIYs use it for things like room correction. But at the same time it is known that it sounds good only when used as purely digital processor bypassing internal ADC and DAC.

I bought one of this devices via Craigslist few years ago with a goal to suppress some modes in my music room. I tried it there between pre- and power amplifier, but felt that it was not transparent enough comparing with the rest of my audio chain. I also tried it between digital transport and preamplifier and felt that it is better works that way, but considering that I use analog sources too, I couldn't really use it. So Behringer went on a shelf, and stayed there for almost two years. Recently I decided to give it another try, this time not in stock form and shape.

But what is exactly wrong with analog to digital and digitral to analog processing in DEQ2496? Several people measured performance of DEQ2496 in analog domain and found it unsatisfactory. One example you can find here: Archimago's Musings: MEASUREMENTS: Behringer DEQ2496. As you can see numbers (other than jitter) do not look too bad. But more serious problem can be found from measurements on this page Behringer Mods - Upgrade DEQ2496, DCX2496, SRC2496 It is clear that DEQ2496 has very high level of IMD at high frequencies. Picture shows that odd order intermodulation harmonics reach -70dB level - that should and is considered very poor for modern device. I did similar series of measurements myself . I used SpectraPlus 5 software and old, but still excellent EMU 0404USB audio interface (Archimago from link above used it too). EMU has distortion level many times less than DEQ2496, thus my results were not significantly affected by its own distortions. Below you can find distortion spectrum for 1 and 10 kHz tones, 19+20 kHz and 60+7000 Hz IMD test signals and silent test. All these tests were done through main analog inputs and outputs of DEQ2496 running at 96 kHz sampling rate. I also added 19+20 kHz loopback test of EMU interface as a reference.

From pictures you can see that Behringer has high level of harmonic and IM distortion for high frequency signals. Worst distortion spectrum can be observed in 19+20 kHz IMD test, with distortion levels more than 0.1% and odd order harmonics reaching -65 dB. There is no surprise that Behringer sounded rather poorly when used with analog inputs and outputs. As a comparison I did another test in digital domain and as expected there were almost no distortion observed. On the surface DEQ2496 uses high quality Asahi Kasei chips which should provide very low distortion. They are commonly used in studio gear 10 times more expensive than Behringer device. Thus if this is not about actual A/D and D/A chips, then it should be analog part, right?

I will be recapping and upgrading the opamps on my recently purchased DEQ2496.

I noticed that the digital board is v2.5. Based on the rigorous work of stef1777 of diyaudio and awdiy.com, I noticed that my board layout was different from the photos and descriptions he provided.

As such, I believe this may be the first DEQ2496 mod featuring the v2.5 board.

The AKM AK5393 ADC has been replaced with a Cirrus Logic CS5381-KZZ and the capacitors around this ADC now include a few 1uF 50V radials which were absent on the previous layout.

See attached photo of the digital board. I have annotated some of my plans, including how I plan to follow stef1777's suggestions to piggyback 10uF 10V OSCONS on some of the ceramic caps. It seems as if there are actually several more candidates for similar piggybacking or outright replacement which I have left without annotation.

I am excited to increase my electrical engineering knowledge as I am an economist by trade so I do have one initial question for the gurus of diyaudio - looking at frequency coefficients, it seems that 50V capacitors have higher (worse?) frequency coefficients versus their 25V cousins (usually on a datasheet you can see both variants side-by-side). I find it odd that there would be 50V caps on this board, especially when it seems this is the first time 50V caps have ever been used on the DEQ2496 (at least on the digital board). Can I use 25V instead? I know this is not a simple question, but perhaps my detailed photo and the experience of this community can help me answer this question.

Thanks!

(I have mostly settled on Elna Silmic II caps for the analog board's 47uF 25V caps, the (ridiculously) more expensive Panasonic OSCONS for the 10uF 25v caps on the digital board, and PPS Film caps for the 1n5, 2n2, and 390p ceramic smds. If I'm feeling sadistic, I may replace some of the 100n and 100p smds as well. There are a few others, for example, stev1777 suggested replacement of C1 10uF 25V on digital board with a 22uF 25V and 2.2uF 50V that I will need to choose as well - <strike>assuming that v2.5 C1 cap is the same as v2!</strike> *there are differences because the ADC is different, see post #12)

I have also included stev1777's awdiy.com picture of the v2 board so you can see the differences (at least some of them).

I'll leave the analog board for a separate post in this thread.

The lead of one of the press fit diodes in the plane’s alternator failed. I think MP504

Hi everybody!
I've searched but couldn't find any mods for my behringer 🙁 . Has anybody upgraded it with better components, like OP amps...? I'm using digital input (optical) and analog out.
All mods are welcome 🙂

Cheers,
Mattias

Dear forum members! STK054 failed in a Sony STR-7025 type amplifier. This type is not available, so a replacement part, STK056, would be installed in its place. In this case, do I need to change something, or do I just solder 056 in place of 054 and it will work? Maybe an idea what can be installed instead? I heard LM1875 could be good for it, I don't know if it requires a big conversion or is relatively simple?

Hi guys,
Long time lurker , I'm trying to build an ECL82 based tube amplifier based on this circuit.

I used an PT from an old EL84 based amplifier


On the B+ I'm getting 380v at no load with a 1k 10w as the dropping resistor @RS is that normal? The secondary of the PT is around 270v. For C20 n C21 is a 47uf 450v cap.

I am doing some sound treatment upgrades to my listening room and plan to build some QRD diffusers. Is there a sweet spot for which prime number to use? I know the diffusers get more involved as the number increases. I kind of like the QRD with 11 wells but I'd like to know more about the major differences and if it's worth higher numbers. My room is about 16 x 30 so it's pretty large compared to many home listening rooms. I'm already doing plenty absorption panels on the walls and ceiling, 8" on the walls and 4" on the ceilings. I can go up to 8" deep for the QRD diffusers which seems to give a pretty wide diffusion range with 11 wells.

Also, is it best to install the QRD diffusers on the wall at first/secondary reflection points?

Thanks,
Milkduds

Hi guys this is Suraj , an electronics hobbyist ,audio lover . I like to design high power audio amplifiers ,trying to learn about hifi audio stuff like hifi tone control , class H amp , Class D amp . And lot of experienced members are here , so it will be easy for me to learn complex stuff .

Hi folks,

I have been working in my home theater to replace the Martin Logan Dynamo 1000 sub with diy ones. After a bit of reasearch, I settled onthe Dayton Ultimax UM15-22 which are 15 inch dual voice coil 800W drivers. I have a couple of friends that have pro power amps and I decided to go with a Crown K2 because it has no fan which is great for HT use.

I found a K2 amp in a pawn shop for a good price, but it needed a bit of love so i stripped the electronics and send it for a powder coat. I was not able to take of the face overlay sticker withouth damaging them so I redid the layout and laser engraved some durablack sheets to replace the stickers. After seeing that my friend wanted to do the same so we did the same treatment to his but wil silver stickers. See pictures attached!

Afterwards I ran some simulations with winISD to compare the Sealed vs Ported enclosure. 9cu ft ported tune at 19Hz vs 4.5 cu ft sealed enclosure. It obviously the sealed showed a more promessing response... but what the heck... let's build them both and see how they compare in the real world!

So i did just that and was surprised to see how the results are close to the simulations! The ported enclosure (9 cu ft), although twice the size of the sealed (4.5 cu ft) one, won the contest hands down. The bump arount 45Hz is my room mode that I haven't treated yet...I just need to build a second one and finish them up.

So there it is, hope you enjoy!

I found a couple of Thordarson Transformers in a scrap pile. Tested continuity and seems good, couldn't find any info on the catalogue online. The models are T 40378 , T8424 ,6792 ,T69S75 . I think the later are output transformers . Any info would be greatly appreciated.

Hi
first let me thank @BSST , @Mooly , @pitbul again for all the effort on my previous experience with a pair of Kenwood L08M.

https://www.diyaudio.com/community/threads/kenwood-l08m-circuit-discrepency.400634/

I have another pair which I am working on and need some insight and guidance.

Current Status:

All caps have been replaced (except the main power supply caps)
The 10 ohm and 2.7k 3W resistors have been replaced.
New relay installed
Q25/Q26 installed
R51/R52 installed
all other components installed
D8-D9 Shorted
C17 shorted
Input shorted
Q29/Q30 (drivers installed)
all relays click and dim bulb off.

The not so good news

In this state the base of Q29 and Q30 are both -0.4v, where as I would expect that Q30 should be +ve rather than -ve

I should also add that there is no voltage across R51/R52, or R57/R58 which implies the front end is working as it should.

additionally when the 2SA output is installed- the relays click and the dim bulb goes off, suggesting that the negative rail side is OK,
however when the 2SC is installed, the Dim bulb goes on and no relay click

any help greatly appreciated

Peter

No doubt this phono pre is one of my favorites. Now I need to find one to buy for a friend. LMK

Has anyone performed a sonic comparison between the three tubes? Do they sound exactly alike, or
sonically different? If different, how sonically different?

How about longevity?

Thanks

pos

Am a complete beginner with DIY audio, with zero experience, so will probably not have supplied enough info here, but it's a start....

I have a VideoLogic Sirocco system here, on which the sub-woofer driver has disintegrated. The foam surround has fallen apart, as seems to be usual with the Audax drivers used in these VideoLogic systems. I had a pair of the mid-range drivers - also Audax - fall apart in exactly the same way several years ago. Fortunately, managed to find some good replacements units on eBay.

The subwoofer driver in question is an Audax AP170M2.

17cm unit. 6.5" paper cone, polymer chassis. 8 ohms. 45W nominal power. Spec sheet attached here.

The woofer cabinet is 39cm x 20.5cm x 34cm external, with wall thickness of 1.5cm, giving an internal volume of 19.5 litres. The cabinet has no padding inside, and a single front-facing port.

The Audax AP170M2 no longer seems to be available, and given the method of its demise I'm not sure I'd replace it with another one even if I could find one! Those foam surrounds look pretty feeble, as they were on the mid-range units.

Wondering whether anyone has any suggestions or recommendations for a suitable alternative please.

Initial searches have revealed many options, of which 2 might be:-

Visaton W 170 S - 8
https://www.soundimports.eu/en/visaton-w-170-s-8.htm

Dayton Audio DA175-8
https://www.soundimports.eu/en/dayton-audio-da175-8.html

Also found a Dynaudio Esotec MW 162, but that's £150, and probably far too good for the cabinet.

(Also have a pair of Dynaudio BM15A active monitors here, and they are wonderful, but they're not used all the time. The VideoLogic system is the everyday setup connected to my PC).

The searching has made me very aware that I have very little idea of what to look for, or how to assess the likely performance of any candidates. And have zero experience of any of them to fall back on. i.e. how do they sound, and how might they compare with the existing but dead Audax?

Have just watched this video, which I found very instructive on how to interpret speaker specs and graphs. Though he did a good job, assuming that he’s right.

How to Pick The BEST Drivers For Your DIY Speaker Project
Login to view embedded media
But am still at a bit of a loss as to how to decide what to actually buy!

Can anyone chime in with any advice or pointers please?

Thank you.

Hello everyone from southern Italy, wandering around the net I often found myself on these pages, I have always been a lover of music and its best reproduction but without excess or fanaticism. I recognize the great value of doing it yourself, but unfortunately I am not capable of it except at very low levels, hence my nickname. I have read dozens of pages (without understanding almost anything) and I don't know... maybe slowly... I will ask stupid, absurd questions, unreasonable requests but this is a world that I like, especially because I don't know it and I love the things I don't know. 😉

I have this integrated amplifier for ages as an inheritance. Lately the right channel is not working as it should be. I cannot set the bias adjustment as per service manual. It stays at zero (0). The service manual recommends a +/- 31mV. The left channel i was able to set it. On the other hand , I replaced much of the components on the bias circuit section of the amp after finding some faulty components, i.e. opened diodes, signal transistors, pre-drivers, etc. The output transistors are OK since i tried swapping it with the left channel but still exhibits the same fault.

I measured the DC offset voltage with the left channel as zero and the right channel having a reading of 20mV.

What gives? Any help is much appreciated. Many thanks in advance.

I was recently amazed when I discovered this 5-year-old (pretty new) FM tuner model T-1200 (T1200) from Accuphase:
https://www.accuphase.com/cat/t-1200_e.pdf
https://www.accuphase.com/model/t-1200.html
https://www.accuphase.fr/t1200.htm (good pictures)
https://revolutionturntable.com.au/shop/products/electronics/accuphase-t-1200-fm-stereo-tuner/
https://soundline.co.nz/products/accuphase-t-1200-fm-tuner#mz-expanded-view-698524628483
https://www.stereonet.com/forums/topic/281090-accuphase-t-1200-tuner/
https://www.analog.com/media/en/technical-documentation/data-sheets/ad9864.pdf
It is astonishing to me that FM radio is to be switched off or has already been shut down in some countries (replace by DAB/DAB+)
Interesting to know for me is, what was the motivation on Accuphase to create such a top class FM tuner with DSP technology so as the difference in sound performance compare to old fashion top class device for FM stereo reception like e. g. this unit:

Sequerra Model No. 1
https://sb015eafc300824f1.jimconten... - FM-1 - FM Stereo Tuner (user's manual).pdf
https://skyfiaudio.com/products/the...uner-top-3-ever-made-complete-your-collection
https://www.fidelity-online.de/der-sequerra-fm-1-von-herrn-f-aus-o/

or to similar top class vintage units like K&H FM2002 or Revox B760.

Hello, a pair of unfinished UCD180HG Hifi2000 machined box and heatspreaders.
150€ + shipping

Hi there,
New member here, from Germany/France. Background in power electronics, now working in patent assessment. Hope to get some useful informations for repairs (and you never know, maybe I could make some constructive suggestions ;-))

hello everyone.
i'm looking for a ThatMicPre for sale.

Hi to all experts out there.I just become a pair of LL1689 SE transformers rated for 30mA,now becouse I have with the Lundahls and specific with this typ no experience,plese if someone with experience can tell me if I could use this in the line stage whivh shematics is below.Im using now just simply capacitor pio on ouput.But in my design Im not using 100R resistor on B+ and also no 4.7uf mkp cap from B+ to 6n6p cathode.I will be heppy about any help.

Hi everyone, thanks for letting me join the forum. I'm looking forward to learning from everyone and sharing my experiences.

Has anyone else noticed how the buffer setting under playback option in Volumio affect sonic character?

I run the latest compatible free version of Volumio with a Raspberry 5 8GB and use the USB output to feed a Topping D90III Discrete DAC. High Resolution music files are fed from an attached HDD. My observation is as follows:-
1. With the buffer setting at 12MB the sound is perceivably more impactful. But this impact is because of everything in the music becoming more apparently defined but actually a bit strident. Sound stage increases in width and height. Good recording sound good whereas bad recordings are unlistenable.
2. With the buffer set to 1MB the sound stage decreases in width and height but increases in depth. The music is more soulful, analog, better timed and very relaxed. The stridency simply disappears and even bad recordings are just about enjoyable. Good recordings are phenomenal, reminding me of the good old analog days. Low level resolution is excellent.

Any thoughts on this? Thanks in advance.

Hello,

I have built the P3A several years ago, but for my taste, the sound is too clinical. I understand it is built for precision, and it does that very well, but it lacks the "warmth" that usually comes tweaked for branded amps. This warmth, as far as I understand, comes from an emphasis on bass and highs, with a decreased representation of the mid end, making it sound less-harsh and less-tiresome. ( like a V shaped equalization pattern ). So, I was thinking of making some adjustments, and with the help of Chat GPT, I identified some possible mods that I can make, but I would love it if anyone here had the time to validate if these can cause other issues with the amp and if these will actually affect the sound signature towards "warmth" :
low end :

• increase C1 from 4.7 to 10 or even 22
• increase C2 from 100 to 220pf or even 470pf
• increase C3 from 100 to 220 or even 470
• increase C5 from 100 to 220 or even 470
• reduce R6 from 560 to 470 ( will this affect the recommended bias value ? )
• C+, C- increased from 100 to 470 or even 1000

high end :

• increase C4 from 100 to 150pf or even 220pf
• reduce R11 and R12 from 220 to 180 ( same question, will this affect recommended bias ? )
• add 2.2nF capacitor in parallel with R5

It was also suggested to increase R13 and R14 to 0.47 or even 0.56 to tone down the vocals

Another thing suggested is to use a combination of ceramic and metal film resistors, rather than full metal film, even though it will slightly affect precision it will also slightly introduce a tiny bit of pleasant distorsion. Also to use electrolytics instead of Polyprop for the same reason.

What of these advices do you think are feasible ?

Thanks in advance !

Brand: MC (Music Components) Model "DUAL MONO" POWER AMPLIFIER - Schematic wanted

Who can upload the schematic diagrams of this device from Germany ?

My to-read list:

1. Loudspeaker Design Cookbook
2. The Complete Guide to High-end Audio
3. Designing, Building, and Testing Your Own Speaker System with Projects
4. Sound Reproduction: The Acoustics and Psychoacoustics of Loudspeakers and Rooms

And I have already read The Master Handbook of Acoustics.

Any books I should add? I'm aiming to build a set of speakers that I will hopefully never replace, so I want to get it as close to perfect the first time as I reasonably can.

What will the impedance be? And can I put a ~4mH inductor between them to low-pass the bass at around 120 Hz without affecting the mid?

It is being reported by DAC reviewers that the I2S input of a Topping D90III Discrete DAC sounds more relaxed and 3 dimensional than when fed through its USB input. My question is, how is this possible?

The jitter performance of the DAC is -157db whereas the same parameter is specified as 75 picoseconds. I have no idea how the jitter performance expressed in decibels vs time in picoseconds is comparable. But my assumption is that the clock in the DAC is better in specification and implementation. So how can USB input, I2S output of a DDC sound better than the USB of DAC? Thanks in advance.

Dear All,
I need schematics of STAX SR-1 neither SR-1 MK2 nor SR-1 MK2 pro. Mine is SR-1 without any suffix. It was released in 1979. Dislike SR-1 MK2 or later brothers, it has JFET differential amplifier followed by 2SD594 amplifier and finally 2SC1828 emitter follower output. I've drawn most of (but not all) of the circuit by inspecting the board, but I wish it confirmed with your help!

Hi,
I am looking for a power transformer for a Dynaco ST70, preferably with a European primary (i.e. 210-230V).
It doesn't have to be original or come in the same form factor (a standing type might work given it fits under the cage).

Please let me know what you have around 🙂.

I'm thinking on how I can make the most improvement with the easiest method for my Eico ST-70. The schematic shows 440v to the anodes with a 1800ohm dropping resistor to the screens (no choke)that gives 390v. The amp uses a 5AR4 rectifier.

I was wondering how I could make significant improvements without changing design much. I like this amp and am planning to replace a lot of components and tubes.

I have a thought for the power supply that I would like to throw out here. Weber has a power transformer for a Fender Twin rated for 400mA. It has a 320-0-320 and also tapped for 300-0-300. Is it possible to use a SS rectification on the 320-0-320 for the plates and then use the 5AR4 rectification on the 300-0-300 for the screens and preamp section? This would give me voltage very, very close to original specs and do it with a transformer that is made for my home's voltage (which is usually right around 125AC). I could use a CLC after the tube and have the choke be more around 100 ohms (maybe less, haven't checked) instead of 1800 ohm resistor. Much better filtering and much better impedance, correct?

Then again maybe you just can't do this with a power transformer. Thanks for any help.

Hi Folks,

I knocked together a quick proof of concept manifold design subwoofer yesterday and would like some help understanding the measured impedance curve.

Woofer is a JBL 2217 and the cross section of the box looks like this

Here is the impedance measurement vs the Hornresp simulation




I am yet to measure the frequency response, but the lack of height in the measured impedance peaks has me scratching my head and has me wondering if I missed something in construction. The peaks and troughs are encouragingly closely aligned, however.

Is this the sign of a leaking box? A badly braced box? The driver does have a very, very slight rub between the voicecoil and magnet (one that is not obvious unless playing a 10hz wave at high volume of moving the speaker by hand at the right angle) could it be a result of this?

I understand that impedance curves can be very valuable in analysing a DIY speaker, but I will confess to having very little knowledge regarding how to read one.

Any pointers would be appreciated. I haven't been able to find much in the way of explaining this topic when googling.

Two Original and Obsolete 1980's Dual Linear Power Transistor from Panasonic.

Part * : OD503AQ , OD503AP
Brand : Technics
Type : 6 pins Module
Date Code : 1980s
Price : USD135.00/ 1pc
CO : Made in Japan
Payment : PAYPAL
Postage : FREE by Registered Mail ( Singapore Post )

A brief mention of the part in the 1982 Japanese Edition of the EIAJ for your reference.
The heart and soul of the Technics Vintage AMP - the SE-A3.
New old stock , unused and in guaranteed 100% working condition.
Very rare and not easily available on the open market.

* For your requirement , please kindly indicate the actual part # that you want.

I am interested in this tweeters. If anyone have test please share data please.

The seller don't have .FRD and .ZMA then i have no clue about its performance.

Trying to collect some info on various lower priced, larger AMT tweeters. The Dayton and Aurum Cantus get mixed reviews from what I can see on line but no specific info on how they perform crossed lower.

I've tried the larger Dayton AMT Pro 4 and AMT 3-4. My conclusions were they sound a bit rough down low well within their recommended crossover points. The larger Pro 4 was a little worse than the 3-4. Using better dampening behind the Pro 4 helped considerably but didn't leave me feeling confident trying to employ it under 3k, even with steep filtering. It appears the rear dampening can make or break the performance.

I listened to the larger Aurum Cactus AMTs someone sent me to try (didn't see a model number on it). It sounded a bit better than the Dayton Pro4 but I couldn't cross it under 3k either without hearing a few distortion peaks on female voices using various HP filters, both active and passive at 2nd order to 4th order slopes. Once above 3.5k the Aurum Cantus was very good. The upper end sounded extended and effortless, even at eviction level SPLs. The matching between the same model tweeters was however poor with an audible difference in output and channel balance between both. That was rather disappointing after hearing their overall potential.

A long time ago, around the late 90s when AMTs just started showing up on the market, I worked on an R&D project with an independent speaker company in Europe which wanted to get into the AMT market building their own drivers for use in production speakers. It turned out the complexity of design, materials and tooling needed to build an AMT driver with the desired level of performance required more time and money than they were willing to spend.

In that design process, I tried a few AMTs, including models that Mundorf had at the time, which could be readily purchased. Those first gen AMTs also had problems with spurious lower frequency breakup.

Nowadays, the newer Mundorf AMTs sound much better, but they cost a fortune compared to a very good dome or even most true ribbons. I still use planars from Hivi which are pretty good crossed over higher. So far, I'm just not finding any AMTs which fall into that price bracket. The quality control appears to be hit and miss in that part of the market. That's unfortunately rather predictable.

Has anyone compared some of these newer, larger and less expensive AMT models yet and measured their performance?

I always seem to have a project that requires belts less than 2 inches down to around .75 inches
the belt assortments I have got down to around 2 but just a bit to big to work
I saw one person suggest O-rings and the 115 size in particular

does anyone have a suggestion on a particular alternative similar to that.

my goal is to have a bag of assorted belts below 2 inches (1.77 they say) and I currently have an assortment above around 2 inches

these belts are for functions that are not "critical" such as tone arm movement or CD changer tray movement

I don't want to order a belt on an as needed basis as that is very time consuming and very expensive when you do it often enough. I currently have a couple hundred belts but really small ones dont seem to be easy to buy in "bulk"

I buy a lot of stuff from china but with the tariffs I am holding off being unsure what they are going to do with these small packages

Hello diyaudio,

Kicker ZX750.1 No Audio, Relay turns on, red led turns on for about .5 second then off and stays off. FETS seem to be Ok nothing shorted out and getting expected rail voltages along with +- 15V from regulators. Speaker pops just a bit on turn on. Found Q250 in mute circuit shorted between pins on same side of transistor, can't find replacement? Removed Q250 didn't help resolve issue not sure where to go from here without a schematic. Was able to trace audio signal to U11 pin 3 with a scope but not sure what I should see from there? Any help greatly appreciated!

I have a CD of the Minneapolis Orchestra, Rachmaninoff "Symphonic Dances, Etudes..." (Reference Recordings RR-96CD) which has quite an assortment of percussive instruments and can reveal mods which can really clog up the listening experience.

Wondering what those more "skilled in the art" are using to audition or show off their systems.

Jack

I have a pair pf speakers in my secondary system that I'd like to better tune the response and I have a spare DSP, a Dayton Audio DSP-408, which offers 10 PEQ bands per channel. Without bi-amping and adding another amp, is it possible to add another 10 bands of PEQ per channel by re-amping, that is routing the stereo outputs back into the channels 3-4 inputs, then out to the amp, being mindful of the gain?

Hey all. I am interested in learning more about DIY modifications to wired earbuds. I have a background in robotics/SDLC but have yet to dive into an audio project like this, so forgive any beginner ignorance on my questions here.

The specific mod I am looking to do is to take a pair of Apple Earpods USB-C and reterminate them with MMCX connectors. This would enable use of MMCX IEMs while retaining functionality of the existing Apple Earpods inline mic. The reason why I want to do this is because the inline mic on this Earpods cable is miles better than any alternative I've tried, yet I find the earbuds quite uncomfortable. I need a reliable solution for work calls, which entails me traveling a lot. I'm not a fan of wireless earbuds, overear headsets, or standalone mic type solutions. A service provider did this mod already but it's unclear if the microphone retains its function post-mod.

Is this a feasible mod?

Officially introducing my new speaker build. This one is "mostly" done, but unfortunately I won't be done with the second cabinet in time to make it to the Parts Express speaker competition. But I am far enough along that I have something to show.

My goal is to introduce an idea that is attainable for DIY, and I think it has the potential to change the way we do multiple subwoofers. It is not my idea, but I haven't seen anyone else in the DIY space attempt to do an active speaker like this. The idea is multiple active subwoofers incorporated into the main speakers. (It turns out to NOT be cardiod. I pursuied that angle, but did not end up with any promising results.)

My finding so far is that I can effectively control low frequency response in my room with DSP adjustments to the 4 subwoofers. I also get incredibly clean and detailed bass. I don't know if this configuration will work as well in every listening room or home theater, but I am optimistic. I would like to see other people explore the idea and see if their results are similar. I think that it is possible to use 8" or 10" drivers to achieve the same results, but in a smaller cabinet.

----

The story behind the build is that approx 1 year ago I was inspired to build a DIY version of the Genelec W371A. I was inspired because I saw it as a clever implementation of multiple subwoofers. Normal multiple subwoofer systems employ multiple subwoofers that are external to the main speakers, and placed around the room. But then Genelec made a speaker that to my eyes appeared to combine the subwoofers into the main speaker cabinets. I didn't know if it was really a multiple subwoofer system or something different, but I wanted to find out if it did work.

My intention was to build a W371A, but in a form factor that is more suitable for a living room. I chose to use 12" woofers for the front, and a 10" subwoofer in the rear. (Genelec used a 14" front woofer and a 12" rear woofer.) I built a couple prototypes to test the viability of the idea, and I quickly found that the concept of placing 2 subwoofers in the same cabinet was effective.

The next evolution happened when I was researching what studio monitor I wanted to use with my cabinets. I was hoping to find a pair of Genelec 8050s. But as I researched this project, I decided it would be more cost effective to make the speakers full range. I thought to myself that I might add a coaxial driver. Then a member suggested adding a 12" pro audio coaxial driver.

Now the origin of my design is slightly confusing with Genelec's recent announcement of the 8381A. My design has ended up being something like a smaller 8381A, which is kind of cool. (I don't presume that the performance of my design rivals that of Genelec's, but mine was slightly cheaper!)

----

The cabinet is 16" x 16" x 52", and made of moisture resistant MDF with a skin of carbon fiber cloth (carbon is primarily for aesthetics.) The drivers I'm using are B&C 12FHX76 12" Coaxial, Lab 12 12" woofer, and RSS265-HF-4 10" subwoofer. It is powered by an Emotiva XPA 8 channel amp (6 high power channels + 1 stereo channel). The signal processor is a Peavey VSX 48E. (Cooling fan delete is a critical mod to the Peavey processor!)

The subwoofer plays down to 20hz, and the front woofer has a steep high pass at 50hz. The mid woofer crosses to the horn at 1,200hz. I keep experimenting with the crossover points for the subwoofer, woofer, and mid, so I can't specify what works best.

The port design is something I'm proud of. Early on I decided I wanted the speaker to be 16"x 16", so the radius port design was the only solution that seemed viable. A lot of thought and experimentation went into the port, but I'm not sure what to say about it here. In terms of port noise and resonances, it seems to be as quiet as a Genelec "laminar spiral enclosure" subwoofer. I'm not sure what else to say. Ask if you have questions.

I'm powering the speaker through Speak-On connectors. It's a super clean way to power a 4 way speaker.

Remaining issues: The finish is OK from a distance, but needs a good polish. Maybe needs to be sprayed again to be "perfect". (Automotive 2k clear.) I still have to make the bezels to cover the edges of the drivers. Originally I was going to do aluminum, but now I'm leaning toward black. Black will give a subtle contrast to the carbon.

----

Below are some photos from the build.

Pcbs Tubelab se first version

http://tubelab.com/designs/tubelab-se/ with 2 regulator Sharp PQ5EV5 voltage regulator 1 is extra

Amb a1

https://www.amb.org/audio/sigma11/ pcb v2

free Mystery Borbely PCB

$55 $6 us shipping

3 sets of pass labs pcbs

2-f5 clone

4- m2 non-feedback designed by Absolute Audio Labs out of thailand

$50 $10 shipping

SOLD

looking for toroids 230v / 600va. 2 or 4 secondaries of 18 to 24v.
Looking for multiple of these puppies.

I have a Focal Vestia No.4. I have upgraded all the components on the crossover with their original values. They all consist of Jantzen Audio brand air core coils, capacitors and resistors. For testing purposes, I have only upgraded one of the towers. However, there is a decrease in the bass compared to the original. The bass of the other one, the original tower, is stronger. What could be the reason?

The values of all the components in the new crossover and the original crossover are the same, in other words, the coils and capacitors were all used at the same value. In fact, when they first arrived, I measured them all one by one with an LCR meter for confirmation and compared them with the originals. They are within a tolerance of 1-2%.

Why might the bass be weaker? The bass speakers in the original crossover were connected with reverse polarity, so I did the same. I wonder if I reverse the polarity again and connect them with straight polarity, will it be fixed?

Hello,

I was making measurements of a system that I am building and I notice that I have two quite different results if I use the QA403 software or REW (via the ASIO drivers).

For the moment I do not understand the difference or where is the setting error.

Both included curves measure the same equipment. I just switch between the two softwares.

Has anyone already encountered this problem?

Regards,

Stef.

Looking for a automated turn table for taking speaker measurements
will pay if someone can build me one.

I've been reading as many of the other El34/MA based threads and I'm just as, if not more, confused as when I started.

I picked up a Magic eye version of the quad EL34B PP XD-SE Music angel amp and have since discovered there are many variants.

Mine is red plating on one of the Valves, so I thought I'd start out by checking and adjusting the Bias.

The chap I bought the amp off supplied a handy bias measuring tool for an additional few quid which is indicating 30-31 on 3 of the EL's and 34-35 on the one thats red plating.

Trouble is, it's a bit confusing underneath as to which of the 6 pots adjust the bias, and I was hoping someone on here could point me in the right direction.

I've attached a few images, hope they come out.

Here is the red plating Valve doing its stuff:

And a picture of the underside, with some labels in case someone can match up the numbers and letters to explain which pot does which valve:


I've also noticed a few other troubling things...such as no earth connection to the chassis... although it seems that the Ground on both Input and Output have continuity to the chassis....
I guess I need to deal with one issue at a time.

Any help greatfully received!

Hello everyone!
Need help with a Denon PMA-100M amplifier. In the attached picture you can see what kind of noise appears on the left channel in the default situation, as well as a picture of how beautiful the wave is with a 1000 Hz input signal and no noise is heard. Only the left channel does it. Unfortunately, the repair manual is only available on the Hifi engine page, and there is currently no registration there. Please, if anyone can help me download the repair manual or has an idea what could be the cause of this noise in the left channel, please help me! Thank you very much!

The price is 7 Euro per piece

Hello folks,

Having searched the site unsuccessfully for any content on the NewClassD Neutrino Clock upgrades (i.e. NOT the NewClassD Neutron Star clock!), I open this thread to hopefully get useful feedback...

I'd be very grateful for any performance experience reports from people having done Clock upgrades with Neutrino as I'm planning to do so for my DSP ADC/DAC unit, potentially for my streamer and CDP.

Thanks for feedback!
Winfried

Hi all - long time lurker, first time poster. I've used this forum as a valuable resource to projects, but have long been doing so in the dark. As I take on more projects I'd love to be a more of an active and contributing member.

Cheers,
R

Hi everyone

I've just rejoined, as my old membership used a now-defunct email provider! I've been an enthusiast for many years (too many for comfort!). I started out with a Garrard deck, Trio/Kenwood amp and Wharfedale speakers, then progressed to a Connoisseur BD1 kit in home-made plinths (two designs, in fact), and after that used a Systemdek II for many years, with a variety of arms. More recently, I've been running Nottingham Analogue decks and am currently using an Ace Spacedeck, fitted with a Rega RB880. There have been several arms on this deck, including two Origin Live models, and a variety of cartridges. At present, I'm using an Ortofon Quintet Black S.

Phono stages have included two Musical Fidelity models, which were somewhat modified over the years, but the poor quality of the PCBs limited what could be done. I'm currently using the company's MX-VNYL, which seems much better-made. I also have a Lounge Audio head amp and phono stage combo, and a couple of SUTs (one of them modified).

I am using an Arcam CD player, and previously a NAD and two Rotels (RCD-965BX). The Rotels were fitted with an upgraded clock and other mods, which improved things, but sadly the transports played up.

Amps have included Rotel, Arcam and Cambridge Audio models, but I'm currently very happy with a Marantz Model 50. Speakers are Dali Opticon 2s at present.

Hey guys,
I am from Slovakia. I've been interested in audio technology since high school. Since I am a big fan of quality audio but don't have the money for it I am forced to build it myself. After reading a lot of threads on this forum I decided to contribute some wisdom as well.

These transistors were used as high-frequency drivers (ft=20MHz) in old USA amplifiers. The price per piece is 9 Euros. Or make an offer for the two original packs of 50 + 50 transistors.

Been a while. Thought yall might get a kick out of this one. Tiny 75mm X 15mm free swinging ribbon in a huge cardboard horn. Response +- 2db out to about 13Khz all crossed around 350 Hz to a cheap 7 inch cone in a box. Old Goliath sub to fill in the bottom. A test of extreme's on the ribbon. It is alive, it is dynamic, it is present, it is emotional, and it does not have a hint of horn color IMO. I love big horns, and no crossovers above about 300hz-500hz . And almost any woofer sounds great below this point. In some ways the best sound Ive heard in a while. Humbling how audio can do this with such crudity if size not a concern ha. way more fun than the serious efforts ha.

It is nothing new for TDA 7439. A lot of people did that, and I am inspired by them. That was my 2nd project on Arduino and TDA 7439 with LCD (16x2). The Dot Matrix LCD was not very impressive for me; for that reason, I just tried to make it colourful with a large display. As a new user on Arduino, it was quite challenging for me. This is my 3rd project on Arduino Nano with TFT ILI9341 display, but I faced a problem after 70% of the code was written. The flash memory of the Nano exceeded the limit, and then I shifted to ESP32. It is my 1st experience on ESP32. I was very confused to choose the ESP board because there are hundreds of types of ESP32 boards! Then I choose the ESP32 WROOM devkit with 2 reasons: 1. I need more flash memory than Arduino Nano. Nano's memory was not enough. And the 2nd reason is that the ESP32 is quite cheap and available in our local market. other hand capacitive touch features available in ESP32. I configure the switching in 3 different ways: rotary encoder, tact switch, and touch switch. The TFT screen is not as good as a mobile screen but much better looking than an LCD. I've used the Sony TV [RM-ED054] remote control, which is also very cheap and available. I have a plan to control the system over Wi-Fi but am facing the problem that "WIFI manager" is conflating with the eTFT library [so far, I guess]! I need to dig more about this issue...

This thread is for a group buy for a new Salas board L-Adapter.

This regulated supply can do ~1.5 to ~20V higher current rates than previous shunt supplies offered by Salas. The board is 136mm x 63mm, 2oz copper, 2mm thick.

The amount of Digital Devices such as Raspberry Pi, wall-wart devices and DACs using lower voltage and increased current is growing and the desire for non Brick or USB power supplies has come knocking on our door for some time.

L-Adapter Technical and Build Thread:

https://www.diyaudio.com/forums/power-supplies/336685-adapter.html#post5761291

The Board L-Adapter USD$18 each




Built up pictures








LED orientation



The BOM for the board is really strait forward. The Transistors do not change regardless of voltage or current. All parts are available from Mouser for those who have easy access and shipping arrangements with them. Minkits will be offered and can shipped as flats internationally for a lower shipping price than full kits. Full kits are going to be offered as well, but will demand a significantly higher shipping costs as the heatsinks and caps require package shipping internationally. Minikits and full kits ship domestically at a lower rate. The full kit based around the expected needs to power a Raspberry Pi. Some lower current devices may not need the diode heatsinks, some higher current ones will need to mount the diodes and the TO-3P transistor directly to a chassis and or heatsink.

BOM below.
L-ADAPTER BOM DiyA - Google Sheets

Why these parts were chosen Diodes, Fuse, HS
The diodes are rated up to 200V and 30A, so these are higher than the regular MSRF860 that I ship with other kits. These can handle more current, have a low vF and are fast recovery. The Fuse is slow blow version chosen via Salas that will be able to handle transients above it's 8A rating. It's being used in the Power supply as part of a CRC Filter. The heatsinks are chosen for common dissipation needs.
Higher cap values can be used than 6800uf, but may need a In-rush current limiter to avoid problems. Caps should all be 105c rated, as this unit can produce heat when being run hard!

Sign up sheet is in my signature. GB Close date is not yet chosen. Please follow thread for updates and interest.

I'd like to present my old design, with double bootstrap. Now slightly refreshed and improved.
This amp allows for 200W at 4 Ohm with only +/- 45V supply. It also has very low THD: only 0.000027% 1W/1kHz and 0.0030% at 200W 1kHz (LTSpice simulation).
Older version was first published on polish DIY forum in 2010, and build by many people. This version so far is only LTSpice simulation.
Now some pictures, gain and phase:


How double bootstrap works at 200W power and 10Hz, levering supply voltage for VAS by 8.2V on both rails.
Bootstrap works from very low frequency, making this design suitable for subwoofers.

This same (for single rail) taken from former (2010) version:

Overdrive response wit square pulse. Slew rate is 24V/us, and bootstrap do not causes any instability.


And finally schematics:

Hi,
I have ordered "SC9235 2CH ELECTRONIC VOLUME CONTROLLER WITH LOUDNESS CONTROL".
I'm a bit confused as I think the datasheet has some printing error or ommision of component values.
e.g.
Supply Voltage VDD 0.3~15 (It maybe 3V to 15V). No problem as I will be using 9V supply
Value of R in series with C2 between pin 4, 5 for loudness control ?
Value of capacitor at pin 9?
INH to be connected to GND or VDD ?
I dont require backup , thus I will ommit the circuit between pin 1, 16

Component values that Im planning to use by reading the datasheet
VDD = 9V
OSC pin 8 : Rx =10K , Cx = 0.1 uF
Supply Bypass capacitor value at pin 16 =47uF

So I need your help to redraw the circuit with proper component values as there's hardly any information about this IC on internet
Thanks

I've had this a number of years. Light use in my hobby room.
Just replaced output valves with matched JJ KT88s.
Genuine 240V model.
Local collection from Wakefield, W Yorkshire, England.

Specifications:
Output Power:
Ultra-linear: 50Wx2
Triode state: 25W x2
Tubes: KT88 x 4, 6n8p(6SN7) x 4 and 12AX7 x 2
Input sensitivity: Integrated 0.25V Rear; 0.6V Front.
Frequency: 5Hz~80KHz (-2dB)
Signal/Noise Ratio: ≥90dB
Harmonic Distortion: <1.5%
Input impedance: 20Kohm
Consumption: 300W
Load impedance: 8ohm or 4ohm
Input impedance: 20Kohm
Colour: Gold Body & Dark Green
Size: 470x380x210 (18.5x15x8.2in) (Deep x wide x high)
Product weight: about 27kg (59lb)
Package weight : about 30kg (66lb)
Input voltage: 240v 50hz.

Hello.

Original V5 group buy thread >here<.

Feel free to post your questions/suggestions in this thread.

Edit: (July 25 2024)

Schematic updated with latest component changes for best operation. Namely, R19, R20, C15, C16.

Hi.I asked seller but he did not respond. Is this board 12db/oct or 24db/oct ? And it seems there is 7 resistors and 8caps. Should not they be same quantity?
I will use them for 225Hz. So is it ok to use 33K dale cmf55 and 15nF kp1830 1% capacitors?
It writes these information on his ebay page
crossover point formula:F=0.707/（2x3.14RC)

sample :

C=1nF R=22K F=0.707/(2*3.14*22000*0.000000001)=5117HZ=5KHZ

C=1nF，f=4.7kHz，R=24k
C=1nF，f=4.4kHz，R=25.6k
C=1.5nF，f=4.1kHz，R=18.3k
C=1.5nF，f=3.8kHz，R=19.7k
C=1.5nF，f=3.5kHz，R=21.4k
C=1.5nF，f=3.2kHz，R=23.5k
C=2.2nF，f=3kHz，R=17k
C=2.2nF，f=2.8kHz，R=18.3k
C=2.2nF，f=2.5kHz，R=20.5k
C=2.2nF，f=2.2kHz，R=23.3k
C=2.7nF，f=2.2kHz，R=19k
C=2.7nF，f=2kHz时，R=20.8k
C=3.3nF，f=1.8kHz，R=19k
C=3.3nF，f=1.5kHz，R=22.7k
C=4.7nF，f=1.3kHz，R=18.4k
C=4.7nF，f=1kHz，R=24k
C=6.8nF，f=1kHz，R=16.6k
C=6.8nF，f=900Hz，R=18.4k
C=6.8nF，f=800Hz，R=20.7k
C=6.8nF，f=700kHz，R=23.6k
C=10nF，f=700Hz，R=16.1k
C=10nF，f=600Hz，R=18.8k
C=10nF，f=500Hz，R=22k

Hi there
I have researched this topic with no obvious conclusion.
let's say I find the brightness of some records a bit much. Is there a way to introduce some form of adjustability into an RIAA passive network that sits between 1st stage (C3G in my case) outputting to a D3A (this is my phono stage. The signal is then fed to a pair of 6G6g in SRPP as preamp)
The network I have in place is derived from the KABUSA riaa calculator
Any help will be appreciated
Nick

Hello, Looking for help with servicing and upgrading Pink Triangle digital products. Or manual / diagrams for a Cordinal

Hey,

NAIM CD5 SX no analog output (RCA or DIN) setting is set correctly. S/PDIF is working.
Anyone have had similar problems and any tips what could cause this?
Anyone have done reverse engineering to draw schematic of this analog board?

My original Carver, as it arrived from the United States over 30 years ago. the only modification that can be seen is the power cable and the plug, because it was fitted with the American one.



CAPS,



I remove the RCA and put the new ones in the same socket








---


in these, which I just took, you can see the caps I used and positioned. I saved the S-bracket and used it to hold the two larger ones.
If I remember correctly, I did the recap in this period of 2024.
in my Carver there is always a hum coming from the power supply and apparently no one has ever figured out how to remove it.
thank you all

I purchased P830985 about 10 years ago for 980 yen per piece (6.34 USD at current rate).
It was sold by a Japanese discount store from the manufacturer's large inventory.
This driver is well balanced and can put a lot of power. It is a true little giant that can be used with many different types of boxes.



Login to view embedded media

Hello,

Modeling 2-way boxes, vented midwoofer + tweeter. Probably it will be BR, but in the past had positive experience with building folded transmission lines for fullranges, so any type of TL is an option.
This is my first multiway project, and the driver selection and matching process kinda scares me a little. With your help would like to get to chose from 4 different woofers.

Hard requirements:
-Tweeter will be Vifa XT25SC90-04
-Woofer choice is limited to these 4
6" SB16PFCR25-4
6" SB16PFCR25-8
5" SB13PFCR25-4
5" SB13PFCR25-8
-Passive crossover. Will use electronic only to sim.
-Best overall experience: good match between those drivers, nice sound for various music listening and so on. Just looking for best package for the amount of money spent.
-Will print part or all of the front baffle with some shallow waveguide for tweeter, to match Z depth/time alignment of drivers, so the vertical distance c-c between drivers will be around the full diameter of the woofer.
-Baffle will have lots of round overs on the edges, as it will be partially or fully printed, as narrow as possible, just enough width for the woofer.

Nice to have:
-Crossover range in the most unobtrusive region. 3Khz+ would be perfect.
-Crossover with a reasonable amount of parts. 1st or 2nd order would be perfect, but not mandatory.

That is pretty much all.

The furniture or CAD sketching part is a joy for me, so no problems there. 3D modeling for printing also is not a problem at all. Have exactly 0 experience in designing crossovers, but started to play with XSim and VirtuixCAD, willing to learn.
There are many positive reviews of SB16PFC25 and SB13PFC25, those rounded corners square shaped, T/S is the same but the SPL graphs are a bit different. I assume, that they are exactly the same drivers, but that does not make the selection easier to me: both have generally positive reviews, there are reviews with the SB13 with exactly the same tweeter and there are reviews of the bigger SB16 with the similar Vifas. I am tempted to choose 6" because "bigger is better" but not so sure if I can cross it high enough for the tweeter to play nice. Speaker will powered by affordable Class D amps, 3116 and likes.

Also: 4 or 8 Ohm?

Any advice on the topic is very appreciated, thank you in advance.
