UGS-muse preamp GB

[Ine]

Thanks Alex.
I will order a OLED display. Most of the other parts are on their way now. Looking forward to solder this project



[CeeVee]

Hi Alex,

I cannot find schematic, BOM or PCB for François' buffer module.

Could you make them available ?



[MASantos]

This one?

UGS_BOM



[CeeVee]

No...that is for the original UGS3 Module

At the beginning of this Project François presented Alex with a surprise...a buffer for the MUSE.

Which is to be plugged on top of the Muse volume circuit.


..installed in ver 1.2.......The UGS Z++



[CeeVee]

knock knock.....all is quiet...



[aspringv]

The Boards look great!

Just received my boards today

Thanks all! Now I just need to learn how to smd solder

For once, I guess I'll be putting together a mouser/digikey order and doing it properly instead of scrounging my way through my spare parts and ebay...



[CeeVee]

Just received my boards today

Thanks all! Now I just need to learn how to smd solder

For once, I guess I'll be putting together a mouser/digikey order and doing it properly instead of scrounging my way through my spare parts and ebay...

If you don't have an USBmicroscope at least...get one is my sugestion....invaluable for soldering smd and checking PBCs like this....especially the control PCB.



[aspringv]

That's a good suggestion - thanks!

I have to confess that it's the possibility of needing to troubleshoot that I'm particularly not excited about! That said I'll give it a try at the least!



[Dennis Hui]

If you don't have an USBmicroscope at least...get one is my sugestion....invaluable for soldering smd and checking PBCs like this....especially the control PCB.

Thanks for the headsup! Will have to look into this.



[Ine]

Hi,
a microscobe is a must to get a good result. I will do all the SMD-soldering with a professional microscope (not USB) at my workplace. A will use a soldering station (meant for smd soldering) .
As mentioned above, the Controller Board is the hardest part. I got most of the parts now, and i will start with the Controller Board some time next week. I can post some (microscope ) pictures, if anyone is interested ?

B.R
Johnny



[Dennis Hui]

Hi,
a microscobe is a must to get a good result. I will do all the SMD-soldering with a professional microscope (not USB) at my workplace. A will use a soldering station (meant for smd soldering) .
As mentioned above, the Controller Board is the hardest part. I got most of the parts now, and i will start with the Controller Board some time next week. I can post some (microscope ) pictures, if anyone is interested ?

B.R
Johnny

Please post some pictures when you have them. SMD work is
very daunting for me.

Dennis



[Ine]

Hi,
will do SMD soldering is practise, practise....till you get hang of it. Do the practise on something else than these pcb´s. I am still in a learning phase, so my colleague at work will do the largest chips. He is a real pro



[Ine]

Hi Alex,

I cannot find schematic, BOM or PCB for François' buffer module.

Could you make them available ?

I am also interested in this buffer module ! Some info would be great

B.R
Johnny



[aspringv]

Yes, please do! I would love to see how a good job looks in this context.



[Ine]

Hi,
has anyone in this GB (in this forum) started soldering these pcb´s ?
It is so quiet in here ?

Johnny



[MASantos]

I won't be building mine anytime soon. Maybe next year!



[Ine]

Some SMD soldering

Have started with the UC pcb.

Pictures:

Muse Slideshow by Ultimate_photos | Photobucket

B.R

Johnny



[CeeVee]

...Nice ...starting mine as well .



[Ine]

Some more pictures

From the start:

Muse Slideshow by Ultimate_photos | Photobucket



B.R

Johnny



[kasey197]

Wow looks good Johnny !
