This is my new phono preamp. I designed it for playback of a friend's LP collection, it can equalise records with the RIAA, AES, FFRR and NARTB curves. It uses both series and shunt regulation to feed a single opamp based gain stage with an active filter, including a BUF634 current buffer to allow the opamp to drive the capacitive load the filter presents.
