More build with toroids.
GU50 mono blocks,no hum no hiss.
klaar GU-50 PP.jpg

You can never have enough Trainwreck Express clones amplifiers.
That's why I built another one. Now with a shield over the toroidal transformer.
I use a 5mm thick aluminium tube there.
Post PI Master volume and tube FX send/return.
The amplifier sounds quieter in terms of background noise than the previous one.
The small changes I made are the ground of the PI and Presence now goes to the HV EL34 ground and not the preamp ground.
Now I just have to build it into the wooden cabinet.


Attachments

  • DSC09245.JPG
    403.1 KB · Views: 39
  • DSC09235.JPG
    350.4 KB · Views: 37
  • DSC09233.JPG
    472.7 KB · Views: 37
  • DSC09232.JPG
    545 KB · Views: 40
  • DSC09225.JPG
    573.8 KB · Views: 35
  • DSC09214.JPG
    422.8 KB · Views: 36
  • DSC09178.JPG
    375 KB · Views: 31
  • DSC09176.JPG
    500.3 KB · Views: 32
  • Cesspool  aangepast 2.jpg
    Cesspool aangepast 2.jpg
    117.9 KB · Views: 33
  • bias print.jpg
    bias print.jpg
    51.2 KB · Views: 37
the tube amp is difficult to repair?
No, if you know what to do. Look on You tube for the videos in which tube amplifiers are repaired.
If it seems too difficult, don't start!
What helped me was to divide a schematic of the amplifier into pieces and then fabricate each piece.
But you should never lose sight of where you put everything and how big your amplifier space will be.
I didn't know anything about it either, but learned by doing.

The people who post their builds here also started out that way.

And you have to love music, it will help you to find your goal.
