I ran simulations of the F5m using irfp240/irfp9240 spice models since I could not find 140/9140 models.
Yeah, the power requirements for R3, R4, R5 can be reduced, but at the expense of lower open-loop gain and more distortion. The change had negligible affect on bandwidth, requiring R1 to remain at 22K.
Papa wins, as usual.
Yeah, the power requirements for R3, R4, R5 can be reduced, but at the expense of lower open-loop gain and more distortion. The change had negligible affect on bandwidth, requiring R1 to remain at 22K.
Papa wins, as usual.
The spice models you are looking for are available here. I hope it helps.Does anyone have spice models for the IRFP140 and IRFP9140?
I have built the F5m using easily modified DIYAudio Store F5 boards from long ago. I installed the boards on my prototyping chassis configured to handle the FirstWatt standard +/-24V power and a subset of the Universal Mounting Spec heatsink holes.
Since my heatsinks are fairly large (7" tall Heatsink USA 10.080" wide C/W/3": approximately .80), I biased the output FETs at around 1.35A, giving a heatsink temperature rise of 23C.
The distortion measurements are consistent with what Papa showed in the BAF 2023 video presentation.
The damping factor measured at around 26.
How does it sound? Amazing for such a simple amplifier, A/B listening against more powerful and lower distortion amplifiers. Plenty of power for my 88dB sensitivity speakers in rather large room.
Hats of to Papa, the circuit magician.
Since my heatsinks are fairly large (7" tall Heatsink USA 10.080" wide C/W/3": approximately .80), I biased the output FETs at around 1.35A, giving a heatsink temperature rise of 23C.
The distortion measurements are consistent with what Papa showed in the BAF 2023 video presentation.
The damping factor measured at around 26.
How does it sound? Amazing for such a simple amplifier, A/B listening against more powerful and lower distortion amplifiers. Plenty of power for my 88dB sensitivity speakers in rather large room.
Hats of to Papa, the circuit magician.
Diy management is attracted to the inclusion of a power supply pcb in the essentials kit.
There will be a slight delay while it travels across the Pacific...

There will be a slight delay while it travels across the Pacific...

By reading rhis I imagine how his back looks…Chris Dollar (duck552) sat in front of a camera for two days recording
Very silly notfunny joke, I know. sorry
