PCBPCBs for Nelson Pass‘ CSX1 SONY VFET amplifier

[davelang]

Large CSX1 caps

There are lots of available devices for the large caps. Search for 22000uf 50V electrolytics. They are 5 pin devices(three are anchoring pins). Here is a link to the Vishay specs for the 051 devices if you gotta have the real thing



[bk856er]

All is clear now, thank you. The 5-pin and BC/Vishay thing threw me. It looks like the PCB silkscreen for the 40mm part is correct indicating 40V, but the pdf BOM shows 50V. I usually turn to Panasonic, but not many options there these days.

BK



[bk856er]

40mm 051 caps on the way. Pricey buggers.

I know there's a long VFET thread and a Pass picture thread, but does anyone have pics of completed CSX1 amps to share for inspiration?

BK



[Abraxas336]

To the European group buy people:

All packages are on the way except K.A.B.s - Anders please send me your shipping address.

I put shipping lables on the packages but asked a family member to take them to the post office since I'm currently a bit busy with moving house. Unfortunately I forgot to mention I wanted these posted as registered parcel, not as normal parcel and the lables are the same.

As a result all packages have been posted as a normal parcel. That is not necessarily a problem yet but then I asked for too much shipping costs.

The European parcel costs 7 instead of 14 and the DE parcel costs 2,4 instead of 7.

I will send you money back to your paypal accounts:

7 Euro to: Carlington, lauc, FiReFoX74, zeroalbedo
4,6 Euro to: abc4230, Ralf Peter, nick 89

Soendervig: we will clarify seperatly via email

Best Regards
Sven



[goldkenn]

If there will be another run, highly suggest to increase the size of components holes, it now can't use better components such as Welwyn RC55 resistor since the legs are too thick for the holes, re-drill will be too easy to damage the solder pads.



[K.A.B]

Pm send.


Regards

Anders



[Soundhappy]

If there will be another run, highly suggest to increase the size of components holes

Yes please more diameter for zeners , output audio resistors at last caps
like Nichicon fine gold 220 uF legs are pain to fit in
Best regards



[Nick89]

Hello Sven,
PCBs have arrived today - they look gorgeous. Thanks for the great service and all your efforts. All the best,

Dominik



[lauc]

Hello,

I received my boards yesterday.

Thanks a lot !

Laurent



[goldkenn]

Anyone have a BOM list of recommend components choice? It is really painful to find good parts for the current layout of the PCB, other then resistors, my stock parts such as ROE and Nichicon MUSE capacitor, if not size too big, then is legs too thick, I ordered some ELNA also finally the legs too thick, Vishay/Philips have difference series and I don't know go for which one, also Panasonic, FM? FC? FR? NXL? Or else? I really have no idea what could fit the PCB with right or best match of sound character, any recommendations?



[davelang]

Yes I will repost it this after I get to home base.



[davelang]

Here you go



[bk856er]

Here you go

FYI, as found in post #324 from dsdjoy. Very valuable!

One minor typo is the large BC caps are actually rated 40V (pn MAL205157223E3).

Would love to hear comments/experiences with part choices, although I mainly intend to follow the BOM. I recall reading that certain specified parts will still require enlarging some holes in the PCB. Any tricks or precautions for that particular surgery?

BK



[davelang]

Through plated holes might need to be soldered on both sides if drilled out



[goldkenn]

Here you go

THANKS



[goldkenn]

Forget to as, will anyone going to design the auxiliary boards for the BIAS supply transformers and their rectifiers?



[Soundhappy]

@ Diyers

Think drills in pcb are necessairy to fits some components ,
for don't breaks the tracks i do in two time mouvement
each by one side and in half pcb deep drill
to not push track to extern of surface and avoid bad surprise.
Any tips solutions ? Thanks

Best regards



[K.A.B]

I got mine pcb yesterdays in a badly smashed box thanx to Sven he wrapped the card well so they survived.

Anders



[anilva]

I am interested in a set of boards, if there are any left. I am based in India.

Please let me know.

Cheers.



[wdecho]

I have been fortunate to acquire a pair of permaneder boards from a gracious member and notice that the input voltage is 32 volts so I am to assume the voltage is regulated down to 23 volts on the board. Does anyone have a schematic for the boards? I notice that the buffer is also included on the boards.

David
