my last sims are showing 7mV difference of output DC offset and 20mA difference of Iq , between 20 and 70C
all that having Iq correction circuit , and even let's call it Servo for Iq , but not directly influencing DC offset
all that having Iq correction circuit , and even let's call it Servo for Iq , but not directly influencing DC offset
Interesting. My latest sims show these values over the range 20C to 70C heatsink temperature:
- 50mV difference in Vout
- 5.5mA difference in Iq
-------------------------------------
I do not know what values are used in XA-25.
I believe Mr Pass or Mr. Colburn might want to answer that question.
No, that will be to much, they already gave us a lot.
You was talking about capacitance in feed back network, usualy we can tweak circuit for stability without that.
ZM: What assumptions do your simulations make about the junction temperatures of the JFETs, 2nd stage FETs, and output FETs relative to the simulation temperature sweep. I noticed that bottom of the enclosure shown in the XA25 photo does not appear to have any ventilation holes. Could this be intentional so that the case temperature of the FETs in the FE track closely with the heatsink temperature?
No, that will be to much, they already gave us a lot.
You was talking about capacitance in feed back network, usualy we can tweak circuit for stability without that.
-------------------------------
You probably did not read my comments carefully then.
Interesting. My latest sims show these values over the range 20C to 70C heatsink temperature:
with a single "servo" for Iq. Unfortunately, my current circuit is too sensitive to some component values. I do not know if that can be fixed by adjustmenting other component values.
- 50mV difference in Vout
- 5.5mA difference in Iq
40mA diff stepping rails from 40 to 15
falling down at 10 and 5V rails
DC offset change in range of 10mV
I believe it shows non critical values , except in setting where trimpot is
(full rotation of 5R trimpot is giving change of 740mA of Iq

regarding junction temp - I'm not exactly advanced LTSpice user , just pasted simple line got from generg (.step TEMP 20 70 5) , and tested accuracu of that line in sims of some of well known circuits/builds , so I resume (and hope) it'll follow even in this case
Have you managed to reduce the total number of trimpots per channel to 2 and still be able to adjust for Iq and FE bias currents?
BTW, using a slightly more complicated circuit I am getting 8mV offset change and 1.5mV Iq change for 20C to 70C. Stepping the rails from 20 to 40 I get 18mV offset change and 50mA Iq change at 50C. I haven't tried to optimize this yet.
Other issues to address:
BTW, using a slightly more complicated circuit I am getting 8mV offset change and 1.5mV Iq change for 20C to 70C. Stepping the rails from 20 to 40 I get 18mV offset change and 50mA Iq change at 50C. I haven't tried to optimize this yet.
Other issues to address:
- K2/K3: The control of even harmonics which exceed the odd harmonics by as much as 40dB without any adjustment. This requires attention at both low and low frequencies.
- Phase margin and overshoot:
- PSSR: Can we achieve good bias stability and low PSRR with only the 4 capacitors on the FE board and the 18 capacitors on the PS board, or are there more capacitors on the PS board that cannot be seen?
besides CRC in PSU , I have just two caps (4700u/16V) on FE and third between puck gates (10uF)
just one trimpot
of course , speaking of sim
due to other obligations , it'll be in vivo not before a month or so
regarding THD , this is what I'm getting
Harmonic Frequency Fourier Normalized Phase Normalized
Number [Hz] Component Component [degree] Phase [deg]
1 1.000e+03 4.124e+00 1.000e+00 -0.07° 0.00°
2 2.000e+03 1.786e-05 4.331e-06 1.70° 1.77°
3 3.000e+03 1.803e-06 4.372e-07 89.44° 89.51°
4 4.000e+03 6.422e-08 1.557e-08 -178.01° -177.94°
5 5.000e+03 1.902e-08 4.612e-09 -155.46° -155.39°
6 6.000e+03 1.434e-08 3.478e-09 -177.08° -177.01°
7 7.000e+03 1.221e-08 2.961e-09 -177.37° -177.30°
8 8.000e+03 1.067e-08 2.589e-09 -177.78° -177.71°
9 9.000e+03 9.403e-09 2.280e-09 -177.86° -177.79°
10 1.000e+04 8.402e-09 2.037e-09 -177.96° -177.89°
Total Harmonic Distortion: 0.000435%(0.000325%)
just one trimpot
of course , speaking of sim
due to other obligations , it'll be in vivo not before a month or so
regarding THD , this is what I'm getting
Harmonic Frequency Fourier Normalized Phase Normalized
Number [Hz] Component Component [degree] Phase [deg]
1 1.000e+03 4.124e+00 1.000e+00 -0.07° 0.00°
2 2.000e+03 1.786e-05 4.331e-06 1.70° 1.77°
3 3.000e+03 1.803e-06 4.372e-07 89.44° 89.51°
4 4.000e+03 6.422e-08 1.557e-08 -178.01° -177.94°
5 5.000e+03 1.902e-08 4.612e-09 -155.46° -155.39°
6 6.000e+03 1.434e-08 3.478e-09 -177.08° -177.01°
7 7.000e+03 1.221e-08 2.961e-09 -177.37° -177.30°
8 8.000e+03 1.067e-08 2.589e-09 -177.78° -177.71°
9 9.000e+03 9.403e-09 2.280e-09 -177.86° -177.79°
10 1.000e+04 8.402e-09 2.037e-09 -177.96° -177.89°
Total Harmonic Distortion: 0.000435%(0.000325%)
I forgot fourth cap - lag cap , in range of 470p or so
but , what's gonna be there is matter of real world processing
but , what's gonna be there is matter of real world processing
ZM: Two questions:
- How sensitive to choice of JFET Idss are your temperature sweeps? My simulations get best results with JFETs having high Idss.
- In your LTSpice temperature sweeps are all devices assumed to be at the temperature specified by the global variable TEMP?
1. not sensitive ; even tried changing drain resistance up 50% without significant change in output offset
2. frankly - ZM knows station about that ; command is just one .step TEMP 20 70 5 , it would be logical that entire shebang is influenced
btw . Generg just sent me his own killer iteration ....... superb in every possible way , except it is having higher value for series resistors than I'm willing to accept
so , I'm going to stay with my ( as usual) over-complicated thingie ...... having green all around my head , because my own Wakoo German made it so gracefully
it's pleasure to enjoy Joie de Vivre he's always bringing to this hobby ..... 🙂
2. frankly - ZM knows station about that ; command is just one .step TEMP 20 70 5 , it would be logical that entire shebang is influenced
btw . Generg just sent me his own killer iteration ....... superb in every possible way , except it is having higher value for series resistors than I'm willing to accept
so , I'm going to stay with my ( as usual) over-complicated thingie ...... having green all around my head , because my own Wakoo German made it so gracefully
it's pleasure to enjoy Joie de Vivre he's always bringing to this hobby ..... 🙂
Attachments

I was so delighted with Generg's solution , tried all things - Vcc step , Temp step , THD ..... that I didn't tried one of most important things - longer time sim
bummer , it's oscillating low ...... motorboating
anyway ..... who cares ....... Joie de Vivre is always there ..... fun is in searching new solution

Problem with motorboating is solved.
:--)) values in Spice look good, means stability agains voltage changes, and temp command.
Still open PSSR behaviour and who knows what else......
:--)) values in Spice look good, means stability agains voltage changes, and temp command.
Still open PSSR behaviour and who knows what else......
There is No result anymore when I give in
6moons XA25
Hm, hm....even no more any mention of newsroom.
6moons XA25
Hm, hm....even no more any mention of newsroom.
Last edited:
Maybe Papa has been tweaking us all along and the XA25 is not really a product. 😱
Or maybe he is waiting for one of us to solve the bias stabilization problem. 😉
Or maybe he is waiting for one of us to solve the bias stabilization problem. 😉
Maybe Papa has been tweaking us all along and the XA25 is not really a product. 😱
Or maybe he is waiting for one of us to solve the bias stabilization problem. 😉
http://www.diyaudio.com/forums/pass...gh-end-off-topic-thread-2261.html#post5006308
