Old 80's Panasonic Boombox

  1. You need a service manual. Become a member here and get one: FM-AM-FM Stereo Radio Cassette Recorder RX-5085SA Radio Pana
  2. They function as tweeters.
  3. Play a cassette with piano music on it. A slack/worn belt will give a 'warbling' effect to the piano notes.
  4. This is the power supply board. Its a linear power supply utilising a mains transformer. It converts the 230V ac mains supply to the low voltage dc required to power the radio cassette

P.S. Don't think the moderators will be too happy about you setting up a second thread on the same subject.

You could be subject to some 'Earth, Wind and Fire' - see attachment! 😀


Attachments

  • Panasonic Ambience Sound.jpg
    Panasonic Ambience Sound.jpg
    234.3 KB · Views: 163
Pansonic employed a dedicated ambience amp IC in their ambience boomboxes.

An RVIBA6433 ambience amp IC is shown in the radio cassette schematic viewable here: https://www.gfgf.org/GFGF-Schaltplandienst/Panasonic_RXFW18L_sch.pdf

Scroll down to the third page and locate IC2.

Thanks for finding this link somehow, I tried looking for information but could find none, haha. I was messing around with the box and I think I have a better idea of what it does now. I'm pretty sure Ambience "echos" whatever's supposed to go into the rear channel into the left channel also, which probably creates the wide sound stage. If you plug in an mp3 player through the rca input jacks, and disconnect the left or right channel, and flip the switch to ambience mode, the sound still comes from both the speakers but sounds funny. Unfortunately my technical skill is limited, I can't make much sense of the diagram in the pdf. 🙂

  1. You need a service manual. Become a member here and get one: FM-AM-FM Stereo Radio Cassette Recorder RX-5085SA Radio Pana
  2. They function as tweeters.
  3. Play a cassette with piano music on it. A slack/worn belt will give a 'warbling' effect to the piano notes.
  4. This is the power supply board. Its a linear power supply utilising a mains transformer. It converts the 230V ac mains supply to the low voltage dc required to power the radio cassette

Thanks, weirdly seems to sound perfectly fine playing cassettes, so I'm pretty sure someone changed the belts before me.
