Hi what the pro and cons for the arrangement of drivers for the speaker below?
I ask because I have the drivers, not the same, but same size and I am split between a wide baffle and a narrow one.
Narrow:
Wide:
http://www.sonusfaber.com/ContentsFiles/SFweb13_0072edit-Modifica.jpg
I am using a active filter so I can boost the midrange if I decide to use a narrow baffle
I ask because I have the drivers, not the same, but same size and I am split between a wide baffle and a narrow one.
Narrow:

Wide:
http://www.sonusfaber.com/ContentsFiles/SFweb13_0072edit-Modifica.jpg
I am using a active filter so I can boost the midrange if I decide to use a narrow baffle
Last edited:
I have done OB speakers and found that the baffle rattles too much for my liking.
I will be building a baffleless speaker like this one next time:
Hawthorne Audio • View topic - Augie in baffleless design
I will run the main speaker down to 80hz and add a double 18" ripole sub for the lower octave.
I will be building a baffleless speaker like this one next time:
Hawthorne Audio • View topic - Augie in baffleless design
I will run the main speaker down to 80hz and add a double 18" ripole sub for the lower octave.
The Edge is easy to get clear results about what the effects will be.
I found an offset mid driver on a wide baffle to have a much smoother response in real life that needed little eq.
I always try new OB baffles with cheap ply. It only takes me 30 minutes to cut and route a new one.
Also get or make yourself a good router circle jig. Life saver!
I found an offset mid driver on a wide baffle to have a much smoother response in real life that needed little eq.
I always try new OB baffles with cheap ply. It only takes me 30 minutes to cut and route a new one.
Also get or make yourself a good router circle jig. Life saver!
After saying that (haha), more ideas come to my mind. Give a look below and google for more, also in diyAudio.
http://www.diyaudio.com/forums/multi-way/233045-ae-speakers-dipole-15-lo15-need-advice.html
http://www.diyaudio.com/forums/multi-way/233045-ae-speakers-dipole-15-lo15-need-advice.html
Attachments
Last edited:
I know that the sonus and ikea has nothing in common. There are just examples of a narrow and wide baffle. The sonus is 65cm wide from top to bottom playing in 2 pi from around 300 hz and up.MartinAndersen, that open baffle is most likely sounding very good, assuming crossover is well executed. However, they have nothing in common with Sonus Faber.
The ikea needs baffle step corrections to do the same. Not talking about the woofers the of curse needs some kind of equalization for any kind of OB speaker
The Edge is easy to get clear results about what the effects will be.
I found an offset mid driver on a wide baffle to have a much smoother response in real life that needed little eq.
I always try new OB baffles with cheap ply. It only takes me 30 minutes to cut and route a new one.
Also get or make yourself a good router circle jig. Life saver!
I life in a flat and any kind of wood work is a no go
Send PM so we can discuss in private.Inductor, why do you advertise fake interview on youtube?
Download The Edge (freeware) and see yourself!http://www.tolvan.com/edge/help.htm
U-frame makes the baffle wider, which means more bass (less equalization needed). It also shifts dipole null lower, which migt be a problem considering power response.
Please study this excellent homepage for dipole design By Rudolf Finke
Dipolplus - Alles über offene Schallwände
his white paper in english http://www.dipolplus.de/downloads/Open%20baffle%201.pdf
U-frame makes the baffle wider, which means more bass (less equalization needed). It also shifts dipole null lower, which migt be a problem considering power response.
Please study this excellent homepage for dipole design By Rudolf Finke
Dipolplus - Alles über offene Schallwände
his white paper in english http://www.dipolplus.de/downloads/Open%20baffle%201.pdf
That is often a problem, but did you look at the baffle in that photo? Do you think it would rattle?I have done OB speakers and found that the baffle rattles too much for my liking.
