There are Chinese boards available on eBay (no silicon except in the power supply). There's a build thread on Lenco Heaven.
Personally I wouldn't build an EAR clone. A better sounding design, IMHO, is the Broskie Tetra at tubecad.com. He sells the board with manual and if you want all of the parts except the power transformer. A more elegant design than the 834P IMHO.
Steve
Personally I wouldn't build an EAR clone. A better sounding design, IMHO, is the Broskie Tetra at tubecad.com. He sells the board with manual and if you want all of the parts except the power transformer. A more elegant design than the 834P IMHO.
Steve
Member
Joined 2009
Paid Member
Count Duku aside, Thorsten did a mod on this phono that was highly regarded and maybe of interest. I don’t know of a better link than this one but somebody else maybe able to help.
GoodSoundClub - Romy the Cat's Audio Site - About voltage starvation of EAR-834P input stage.
GoodSoundClub - Romy the Cat's Audio Site - About voltage starvation of EAR-834P input stage.
I can add a little to this thread, when I was working for EAR in about 95-97, on one occasion Tim did a special phono box for a pro industry friend with JFET cascode mod bodged in somewhere, and a slightly tweaked EQ, 4.7p iirc, but don't quote me. The Circuit circulating on the web, was originally for the CLEAR kit instruction manual, which was an 834 preamp case with a passive pre and the phono box PCB instead of the line level version, sold through moth marketing. The circuit was drawn by me in PC paintbrush with himself breathing down my neck to make sure I had everything to his liking.
A 12AX7 typically has a plate impedance, rp, of 58k Ohms.
That 58k Ohms in parallel with the plate load, RL is what drives the next circuit.
If that next circuit is part of the RIAA network, it works properly with rp in parallel with RL.
Now, change the input to JFET and 12AX7 Cascode.
The new circuit, JFET + 12AX7, has an increased plate impedance, rp, of perhaps 500k Ohms or more.
That requires the next circuit to work properly with a driving impedance that is essentially RL.
If the next circuit is part of the RIAA network, the values of the RIAA network will have to change, in order to get the proper RIAA frequency response.
Post # 1 schematic does not show the following part of the circuit, but I bet part of the RIAA network is there.
The other two schematics that are posted in the thread, do show part of the RIAA network immediately following the 12AX7 plate circuit.
58k versus 500k makes for a very big change of the RIAA network frequency response.
Change part of the circuit, without properly changing the rest of the circuit . . .
Use at your own risk of having an improper frequency response.
"One small change for man".
One large change required for the rest of the phono preamp circuits, or else it will not fit the RIAA curve.
Just my opinions.
That 58k Ohms in parallel with the plate load, RL is what drives the next circuit.
If that next circuit is part of the RIAA network, it works properly with rp in parallel with RL.
Now, change the input to JFET and 12AX7 Cascode.
The new circuit, JFET + 12AX7, has an increased plate impedance, rp, of perhaps 500k Ohms or more.
That requires the next circuit to work properly with a driving impedance that is essentially RL.
If the next circuit is part of the RIAA network, the values of the RIAA network will have to change, in order to get the proper RIAA frequency response.
Post # 1 schematic does not show the following part of the circuit, but I bet part of the RIAA network is there.
The other two schematics that are posted in the thread, do show part of the RIAA network immediately following the 12AX7 plate circuit.
58k versus 500k makes for a very big change of the RIAA network frequency response.
Change part of the circuit, without properly changing the rest of the circuit . . .
Use at your own risk of having an improper frequency response.
"One small change for man".
One large change required for the rest of the phono preamp circuits, or else it will not fit the RIAA curve.
Just my opinions.
Last edited:
Definitely so, not just an opinion. Everything in a tube RIAA circuit matters, no matter what the topology.
Last edited:
Agreed fully, but still an opinion, in this instance. I am pretty confident the mods were done on a stock board. The eq tweak was to make the RIAA a little more accurate for the pro user. The purpose of the mod performed (by the bearded one, in an ambiance of hushed conspiratorially) was to improve on the already quite acceptable noise floor.
To the OP, if they are still around, you may have an 834p hand tweaked by himself, he may have signed it (dp).
Are the added fets in a newly designed pcb, or are they installed in drilled holes and hand wired in?
If that was addressed to me, they were added to the stock board I don't remember the precise details, in this instance the original "analog" layout, he got in to CAD soon after I left.
Tim got into CAD? Are you sure? I spent forever trying to persuade him to use LTspice, completely without success. I'd even slip in download links to what was then the Linear Technology website but he wouldn't take the bait. Of course you couldn't push it because he was so irrascible and you didn't want to break one of those eggshells. 🤣🤣 But it would have denied us his hand drawn schematics, which you can recognise across a crowded room. Not just the formal ones either. I've got a few of his jottings knocked up on pages of A4 in a few minutes and they're just the same style, though probably even harder to work out what the hell is going on. I learnt a lot from his style of circuit design, and especially his love of the Common Base amp.
It must have been done after TDP accused Romy tge Cat of stealing his intellectual property by implementing Thorsten Loesch mods and posting this version on his infamous site which only people versed in all Philosophy theories and almanacs can decipher. Anyway I made my own clone with the mods and it sounds fine. Very pleasant phono stage especially for classical music replay .
The circuit has really monumental bass and I was initially puzzled with Cats relentless pursuit of bass capable components until an unwanted visitor of his room made the comment that the system sounds thin and etched and actually like a speaker and not like sirens voice.
The circuit has really monumental bass and I was initially puzzled with Cats relentless pursuit of bass capable components until an unwanted visitor of his room made the comment that the system sounds thin and etched and actually like a speaker and not like sirens voice.
EASY-PC. He got some PCs from the local air base iirc. He was very proud of his curved tracks. Would have been late 90's.
