Why no schematic ?

[Woody1911a1]

?



[Woody1911a1]

or two . as in from ac in to signal out . both dual mono and stereo configurations .

i asked this question out of frustration last nite after trying to diagnose a problem .

all's well now , but still ....



[Peter Daniel]

If you click on those two links from LM3875 product page: DIY Chip Amplifier Kits, PCB's, Components and Information. you will find all the required info.



[Woody1911a1]

hey Peter , yes in a way there is "all the required info" yet no schematic/s . no problem . building your amp was a great learning experience for me . guess i'll never know what caused the problem i had . if nothing else it made me think past the soldering of the components . i had to diagnose the problem and in the end a wonderful amp was born .

i'm truly amazed at the sound and itching to solder some more .

Cheers , Woody



[Peter Daniel]

Schematics are on page 3 & 5 of this User Guide: http://www.audiosector.com/nigc_kit-users_guide.pdf
