Does anyone have the schematics and or pics of this amp? The one I am working on has a few parts that are missing .
What i am looking for is Q410 thru Q416 Q510 thru Q516. These should all be the same, they are located on the power supply. Also C425 thru C429 C525 thru C529 also on power supply. The final two are D125 & D126 Which I think will be the same as D325 & D326. These are also located on the power supply.
That looks like the one I have here.
If you don't have a camera, find someone with a camera phone. Even a poor quality photo will show the general layout and may be enough for someone to recognize it.
If you don't have a camera, find someone with a camera phone. Even a poor quality photo will show the general layout and may be enough for someone to recognize it.
does anyone still have this amp available because my has some burnt out components i cant make them out because they are discollered my email is mc5five@hotmail.com if you could just respond i would really appreciate it. thanks for your time.
Thank you, yes i still have the amp, I have taken it apart and it appears that i have 2 resistors that have burned out, i cannot really tell the number of the component because the black from the burnt part is covering the writing on the board from what i could make out: i have a small resistor completely missing it is next to a brown black yellow resistor looks to be in parallel but i could be wrong and the one in the middle is burnt looks to be c101 i think, then i also have another section looks burnt by a 224j100 blue capacitor i think c433
and lastly another resistor its all black so i cant tell the color code i think it is c463. im hoping that i if i change these it might work. i looked at the electronic lines and they seem to be all intact.
and lastly another resistor its all black so i cant tell the color code i think it is c463. im hoping that i if i change these it might work. i looked at the electronic lines and they seem to be all intact.
