Hey Guys.
So I'm dismantling my CD960 to do a belt change. Do any of you guys have the service manual?
Or, how does one do the belt swap the easiest way?
Another question:
The metal hinge (see picture) does it tap into the plastic bushing as in the picture? I accidently dismounted it without paying attention![magnify :magnify: :magnify:](https://files.diyaudio.com/forums/images/smilies/magnify.gif)
It's located on the tray left side as seen from the front.
/Thomas
So I'm dismantling my CD960 to do a belt change. Do any of you guys have the service manual?
Or, how does one do the belt swap the easiest way?
Another question:
The metal hinge (see picture) does it tap into the plastic bushing as in the picture? I accidently dismounted it without paying attention
![magnify :magnify: :magnify:](https://files.diyaudio.com/forums/images/smilies/magnify.gif)
It's located on the tray left side as seen from the front.
/Thomas
Attachments
Last edited:
Hi
SM here : Philips CD960 Service Manual free download,schematics,datasheets,eeprom bins,pcb,repair info for test equipment and electronics
Hope this helps
Regards
Phil
SM here : Philips CD960 Service Manual free download,schematics,datasheets,eeprom bins,pcb,repair info for test equipment and electronics
Hope this helps
Regards
Phil
Hi
SM here : Philips CD960 Service Manual free download,schematics,datasheets,eeprom bins,pcb,repair info for test equipment and electronics
Hope this helps
Regards
Phil
Thanks!
I've always been holding back from free download sites, which I'm not familiar with. Have you downloaded safely from there?
/Thomas
Thanks!
I've always been holding back from free download sites, which I'm not familiar with. Have you downloaded safely from there?
/Thomas
Yes it's safe while you click on the right link, used often and bookmarked
Check your file before opening, a good AV will let your computer safe.
Cheers
Phil
Last edited:
Thanks again!Yes it's safe while you click on the right link, used often and bookmarked
Check your file before opening, a good AV will let your computer safe.
Cheers
Phil
You're welcome.
Some usefull tricks there : http://www.diyaudio.com/forums/digital-source/89200-help-philips-cd960.html#post2226966
I've ordered some belts from this seller : http://cgi.ebay.fr/Philips-Riemen-b...ter_Audio_Hi_Fi_CD_Player&hash=item58835bbc83
Regards
Phil
Some usefull tricks there : http://www.diyaudio.com/forums/digital-source/89200-help-philips-cd960.html#post2226966
I've ordered some belts from this seller : http://cgi.ebay.fr/Philips-Riemen-b...ter_Audio_Hi_Fi_CD_Player&hash=item58835bbc83
Regards
Phil
Last edited:
Another link here, I always use electrotanya and never had any issues with the files being unsafe the download link appears after a while under the preview page it'll say processing then change to "get file": PHILIPS CD960 SM Service Manual free download, schematics, eeprom, repair info for electronics
Belt is "jumping"
So, after I've been changing belts on the CD960, one belt "jumps" (see picture) when the CD-tray travels from open to closed and vise versa.
After I'd dismounted the transport cord (the grey steel wire) to make the belt change, I've been having a hard time making the CD-tray run smoothly.
It should be noted that the belt only jumps whem the transport cord is mounted!
/Thomas
So, after I've been changing belts on the CD960, one belt "jumps" (see picture) when the CD-tray travels from open to closed and vise versa.
After I'd dismounted the transport cord (the grey steel wire) to make the belt change, I've been having a hard time making the CD-tray run smoothly.
Maybe I've winded the transport cord the wrong way, but according to the manual it looks right
It should be noted that the belt only jumps whem the transport cord is mounted!
/Thomas
Attachments
Last edited:
Micro-seki has a similar layout so maybe this photo might be of help:
An externally hosted image should be here but it was not working when we last tested it.
Micro-seki has a similar layout so maybe this photo might be of help:
An externally hosted image should be here but it was not working when we last tested it.
Thanks SonyES
![cheers :cheers: :cheers:](https://files.diyaudio.com/forums/images/smilies/cheers.gif)
Mine looks exactly like that. Further investigation of what might be the cause of "jump" must be initiated ASAP
![magnify :magnify: :magnify:](https://files.diyaudio.com/forums/images/smilies/magnify.gif)
/Thomas
So I've taken a short and terribly shaky video of the "belt jump"
The phenomenon makes the CD tray run very unevenly, which cannot be good for longivity
https://dl.dropboxusercontent.com/u/62229768/MOV_0158.mp4
/Thomas
The phenomenon makes the CD tray run very unevenly, which cannot be good for longivity
It seems the belt drags on the wheel(s). Maybe the belt is too short/thick.? Belts are ordered as original replacements
https://dl.dropboxusercontent.com/u/62229768/MOV_0158.mp4
/Thomas
It looks to me like there's a problem "downstream" from the belts that is causing the problem, the belts look fine. I noticed that the place where the belt "slips" is consistantly in the same spot for both strokes in the cycle. I'd take the drive belt off and run the mechanism through a complete cycle by hand. I think you'll find a spot at about half-way through where the effort increases, possibly from component wear or misalignment.
Mike
Mike
Presumably the cord should be wound such that when viewed from above it doesn't cross. It should have been designed with the top run of the cord on the inside, but I don't know which way round they actually did it.
Remove the inner belt and operate by hand. You might be able to feel where it's sticking.
The clip attaching the cord to the tray appears to be catching on the belt or the small end of the drive wheel.
Is it driven on just one side? If so then sideways clearance in tray bearings is important. Too slack and it can grab, too tight and it will drag.
Remove the inner belt and operate by hand. You might be able to feel where it's sticking.
The clip attaching the cord to the tray appears to be catching on the belt or the small end of the drive wheel.
Is it driven on just one side? If so then sideways clearance in tray bearings is important. Too slack and it can grab, too tight and it will drag.
Thanks for the input guys!
I think that I've found the intruder. The cord arm rides on the inner belt when CD tray travels across it
Now I just need to address the manual on how to adjust the CD tray height.
/Thomas
I think that I've found the intruder. The cord arm rides on the inner belt when CD tray travels across it
Now I just need to address the manual on how to adjust the CD tray height.
/Thomas
Attachments
Last edited:
Was going to say from your video it looks like the arm is catching on the plastic pulley wheel, almost looks like the belt is to thick for the pulley, how does it relate to the old belt size wise?
Stu
By inspection of the old belt, they don't relate
Try refitting the original inner belt.
Will do
Thanks guys
![cheers :cheers: :cheers:](https://files.diyaudio.com/forums/images/smilies/cheers.gif)
/Thomas
