The Effects of Damping a Ported Cabinet

I've just lined my desktop speakers with thin egg-box foam. I admit the speakers sound less boxy. There's less bass in the 100-200Hz region. But I remain sceptical. Doesn't the foam simply reduce cabinet volume?

It's confusing. I've taken apart hundreds of speakers. Some manufactures stuff their cabinets with damping and wadding like the they bought it in a fire sale, others use none.

diyAudio Moderator
Joined 2008
Paid Member
When used at a certain rate, such as when closed boxes are stuffed, the damping actually increases the effective box volume.

Ported boxes are a special case and traditionally builders don't want to damp the bass the box worked so hard to achieve... however if you have box modes, they could possibly be a higher priority.

Ported enclosures traditionally only have absorbent material attached to the internal walls of the enclosure.

Placing stuffing in the body of a ported enclosure impedes the transfer of energy from the vibrating woofer to the plug of air in the port.

Doesn't the foam simply reduce cabinet volume?

The absorbent material on the walls of a ported enclosure is basically transparent to bass frequencies so does not reduce cabinet volume.

Administrator
Joined 2004
Paid Member
In large vented reflex speakers/Ultraflex/Onken it also keeps lots of higher frequency stuff from exiting through the ports. I have Onkens and I have lined 3 walls with mostly lambs wool/felt. Guaranteed >70% lambs wool, no idea what else is in there, but it really helped with combing at the top of the woofer's passband and with harmonics.

  • Like
Reactions: 1 user
Lining the internal walls of a ported enclosure with absorbent has the function of reducing higher frequency reflections and standing waves.

However, excessive padding will take the life out of the reproduction.

It is sometimes better to line one wall and leave its opposite number unlined.

I found lining 3 walls ideal, they are bottom, one side and the back. I don't typically run the woofers beyond 800Hz, and currently crossing at 700Hz., really helps with reflection generated garbage. I don't find acoustastuff or fiberglass nearly as effective.
Yes, interesting. I think that's because the wall lining is particularly good at reducing internal reflections (echoes). Whereas stuffing is better suited to damping cavity resonances, as it resides centrally, as well as near the walls where it's far less effective (think damping a guitar string along its length, compared to at the bridge).

Of course, polyester stuffing is notably useless anyway, as its energy absorption is limited by the fact that its fibres are smooth (unlike wool and fibreglass). (It still may be useful as a means of increasing effective box size though - especially in the case of closed-box subwoofers.)

As for best lining material, I would imagine very thick natural fibres would be best, though I haven't done any comparisons.

  • Like
Reactions: 1 user
I think that's because the wall lining is particularly good at reducing internal reflections (echoes). Whereas stuffing is better suited to damping cavity resonances,

I agree. Lining the internal walls of a ported enclosure reduces internal reflections which could emerge through the woofer cone or port opening and has little to do with the suppression of resonances.

I also agree that natural fibres, because of their random orientation and texture, make the best absorbents.

However, I wouldn't place fibreglass in the same category as wool or cotton - see attached photomicrographs.


Attachments

  • Cotton Fibres.jpg
    Cotton Fibres.jpg
    92.2 KB · Views: 21
  • Fibreglass Fibres.jpg
    Fibreglass Fibres.jpg
    212.2 KB · Views: 20
  • Like
Reactions: 1 user
Doesn't the foam simply reduce cabinet volume?
Not if it's open cell. Closed cell, yes: it's just taking up volume & is useless for acoustic damping purposes.

It's confusing. I've taken apart hundreds of speakers. Some manufactures stuff their cabinets with damping and wadding like the they bought it in a fire sale, others use none.
The 'others' are likely saving money. But it depends on the design. Efficient design is about doing the most with the least -that doesn't necessarily mean 'none' of course. For a regular, well proportioned vented box, typically something like 1in OC-703 bonded acoustic fibreglass board on non-opposing faces should be sufficient to handle reflections etc. -either measure (ideal) or use the old click test to ensure a nice clean impulse. For a box where one dimension is stretched sufficiently to the others (or just a rather large box) for the longitudinal mode to become problematic, then stuffing around Vmax is usually the most effective solution. TLs by intent, or acoustically undersized boxes using stuffing for a 'vitual Vb increase' are different matters of course.

For the measured effects of a few different materials: http://diyaudioprojects.com/Technical/Papers/Loudspeakers-on-Damped-Pipes.pdf

Fibreglass man myself, when possible. Otherwise SAE-F10 wool felt or an equivalent thereof. BAF isn't catastrophic -it just isn't as effective as some, so you do often need to use more of it.
