Old 12th September 2011, 03:17 PM   #1
radio is offline radio  Macedonia
Banned

Join Date: Oct 2009
Location: Bitola MACEDONIA
Thumbs up 100W Hi-Fi audio amplifier!

Hi all!
After a long time whose resih to design a 100W amplifier that is very simple, economical, but it is very good for beginners and the other for home use!
For starters here's schematic (Figure 1).
thanks and cheers !
Attached Files
File Type: pdf Figure 1(Forum).pdf (88.2 KB, 581 views)
  Reply With Quote
Old 12th September 2011, 04:49 PM   #2
diyAudio Member

east electronics's Avatar

Join Date: Jan 2006
Location: Athens GREECE
are you placing this schematic for evaluation?
if you do please say so so people understand .

if you claim that this is a working schematic you need to say more about the construction ,listening impressions, details and fotos of prototype and so on and on ...

if you expect people to construct the ampliier in order to debug any mistakes i think this is a bad practice ..
__________________
SERVICE ΕΝΙΣΧΥΤΩΝ ΚΑΙ ΙΑΠΩΝΙΚΩΝ ΜΗΧΑΝΗΜΑΤΩΝ ΗΧΟΥ www.eastelectronics.gr
  Reply With Quote
Old 12th September 2011, 05:15 PM   #3
CBS240 is offline CBS240  United States
diyAudio Member

CBS240's Avatar

Join Date: Aug 2005
Location: K-town
A quick evaluation shows me this is a poor attempt to modify a quasi-comp output amp to a complementary OPS. The output Z and thus gain will not be the same for positive and negative output swings because Re for T11 is missing.
__________________
All the trouble I've ever been in started out as fun......
  Reply With Quote
Old 12th September 2011, 05:29 PM   #4
DF96 is offline DF96  England
diyAudio Member

Join Date: May 2007
Yes, it looks like a poor attempt to modify an already weak circuit. The VI limiting for T11 has not been swapped to the opposite polarity! The input LTP will be unbalanced due to a simple resistive load. Best ignored.
  Reply With Quote
Old 12th September 2011, 06:00 PM   #5
diyAudio Member

Join Date: Mar 2006
Location: Budapest
And the low-side "over-current protecting" circuit is actually not protecting against anything, just drives the low-side output transistor into death...
  Reply With Quote
Old 13th September 2011, 05:22 AM   #6
radio is offline radio  Macedonia
Banned

Join Date: Oct 2009
Location: Bitola MACEDONIA
Hi all!!
I'm sorry I put the wrong schematic of this amplifier.
The original is this!!

Technical parameters:
Supply voltage: Uccmax=+/- 42V
Output power: Pomax=100W/4R
Frequency response: fo=10 to 83kHz/-3dB
Harmonic Distortion:THD 0.12% for 100W/1kHz; 0.013% at 100W/10kHz
Intermodulation distortion: 0.28% at 80W / 80 +7 kHz
Input sensitivity: approx. 1V
Current protection: 2x3,15A fast fuses
Speed during SR: 14V/us
Min. impedance: 4R

thanks and cheers
Attached Files
File Type: pdf Figure 1(Forum).pdf (83.5 KB, 273 views)

Last edited by radio; 13th September 2011 at 05:51 AM.
  Reply With Quote
Old 13th September 2011, 07:13 AM   #7
44250 is offline 44250  Serbia
diyAudio Member

44250's Avatar

Join Date: Jan 2011
Location: Ugrinovci-Zemun-BELGRADE
Send a message via AIM to 44250
Default hmm...

If he is who I think he is... I'd like that I'm wrong. Time will show. Here in Serbia there was a guy that used to do things at forums just like radio,and behaved the same way. Not just in Serbia,he was active at all forums in ex-YU countries (Croatia diyaudio.com.rh ,Bosnia and Herzegovinia elektronika.ba ,Serbia www.elitesecurity) using diferent nicks:ZX-O,slavko and a few others always offering changed and "impruved" schematics of boraomega's designes and people like him. A few people tried to cooperate with him but soon they all quit. I don't say that the radio is the same person,but they have a same approach to the forums. Hope I'm wrong,but time will tell.

Last edited by 44250; 13th September 2011 at 07:16 AM. Reason: grammar mistake
  Reply With Quote
Old 13th September 2011, 08:04 AM   #8
radio is offline radio  Macedonia
Banned

Join Date: Oct 2009
Location: Bitola MACEDONIA
Quote:
Originally Posted by 44250 View Post
If he is who I think he is... I'd like that I'm wrong. Time will show. Here in Serbia there was a guy that used to do things at forums just like radio,and behaved the same way. Not just in Serbia,he was active at all forums in ex-YU countries (Croatia diyaudio.com.rh ,Bosnia and Herzegovinia elektronika.ba ,Serbia www.elitesecurity) using diferent nicks:ZX-O,slavko and a few others always offering changed and "impruved" schematics of boraomega's designes and people like him. A few people tried to cooperate with him but soon they all quit. I don't say that the radio is the same person,but they have a same approach to the forums. Hope I'm wrong,but time will tell.
I do not know what is the thing here that is mentioned?
Here is 100W Hi-Fi amplifier, so that we focus on the subject!
And for this type of research as you say you have other forums!?
Regars
  Reply With Quote
Old 13th September 2011, 09:30 AM   #9
Johno is offline Johno  Australia
diyAudio Member

Johno's Avatar

Join Date: Oct 2010
Location: Up in the alps - motorcycle heaven
The protection circuit will turn the drivers hard on, but not me I'm afraid....
  Reply With Quote
Old 13th September 2011, 09:43 AM   #10
lineup is offline lineup  Sweden
diyAudio Member

lineup's Avatar

Join Date: Dec 2005
Location: the north
Quote:
Originally Posted by radio View Post
Hi all!!
I'm sorry I put the wrong schematic of this amplifier.
The original is this!!
R19 and R20 should change place in your schematic.
The amplifier may work alright.
Of course there are a lot of practical things to add.
__________________
lineup
  Reply With Quote
