I made it through most of the hundreds of pages of threads on distributed mode loudspeakers (DMLs) around here, AudioCircle and Parts Express' forum, I decided I wanted to try building a couple of my own panel speakers. I did it yesterday and they sound great. Pictures to come, but I'll start with background first for those who are interested but would rather not have to wade through the gigantic existing threads.
To recap what I found in previous DIY threads:
In the next post: the search for commercial composites and honeycombs.
To recap what I found in previous DIY threads:
- Basics of the technology:
- From a Parts Express customer and DIYer: DML Flat Panel | Parts Express Project Gallery
- From Techtonic Audio Labs (owners of the intellectual property from the now defunct NXT): Professional Distributed Mode Loudspeakers |
- Material stiffness and size matter, especially with respect to reproducible frequency range and especially in the bass where bigger and stiffer is better. Weight still needs to be kept down though for efficiency and max SPL to be acceptable.
- The best panel materials DIYers have found so far are, in no particular order:
- 1/8" or 1/4" birch ply
- XPS or EPS insulation, around 1" thick, with the paper coating sanded off and new edge treatment for stiffening such as diluted wood glue or shellac.
- Heavy-duty foamboard or signboard, the preferred brand being Gatorboard: http://www.dickblick.com/products/gatorfoam-board
- Commercially available high quality DMLs use materials not easily available to DIYers.
- For live pro audio, Tectonic uses carbon fiber sandwiched around nomex honeycomb: https://www.youtube.com/watch?v=aFFfQ1b5EQQ
- Podium Sound makes home hi-fi DML panels using what sounds like a one-off phenolic paper honeycomb: 6moons audio reviews: Podium Sound Model 1
In the next post: the search for commercial composites and honeycombs.
Last edited:
Sourcing materials
Carbon fiber and nomex are both individually regarded as unobtanium for most of us DIYers. Personally my threshold for a DIY project is that if I'm already investing my time, even if it's probably going to sound really good, I'd like to keep it under $100 in case the whole project is a wash.
You can buy prefab carbon + nomex honeycomb sandwich in form very close to what's in the Tectonic video I posted earlier (probably thicker, but probably not substantially heavier or less stiff): here it is at Dragon Plate for $40/6x6" square: Carbon Fiber Nomex Honeycomb Core 0.5" x 6" x 6"
In larger sheets for a little under $100/sq. ft.: https://www.pegasusautoracing.com/p...wXxQP0Wy3OQsEwgaBYSwlEcDJgQFO4cuB2hoClCbw_wcB
Even if you buy separate, nomex honeycomb itself is pretty expensive, like $120 for a 40x48" sheet: Nomex Honeycomb Sandwich Core Material in stock | Fibre Glast. Bigger than I thought I'd need, at least for an initial build, but also over total budget.
Likewise carbon fiber: $27/sq. ft. panel: https://carbonfibergear.com/product...mEBDF6D1f1fgrSqHWbl-UE1YroshLgoouuxoCInDw_wcB.
So I had to get a little more creative...
Carbon fiber and nomex are both individually regarded as unobtanium for most of us DIYers. Personally my threshold for a DIY project is that if I'm already investing my time, even if it's probably going to sound really good, I'd like to keep it under $100 in case the whole project is a wash.
You can buy prefab carbon + nomex honeycomb sandwich in form very close to what's in the Tectonic video I posted earlier (probably thicker, but probably not substantially heavier or less stiff): here it is at Dragon Plate for $40/6x6" square: Carbon Fiber Nomex Honeycomb Core 0.5" x 6" x 6"
In larger sheets for a little under $100/sq. ft.: https://www.pegasusautoracing.com/p...wXxQP0Wy3OQsEwgaBYSwlEcDJgQFO4cuB2hoClCbw_wcB
Even if you buy separate, nomex honeycomb itself is pretty expensive, like $120 for a 40x48" sheet: Nomex Honeycomb Sandwich Core Material in stock | Fibre Glast. Bigger than I thought I'd need, at least for an initial build, but also over total budget.
Likewise carbon fiber: $27/sq. ft. panel: https://carbonfibergear.com/product...mEBDF6D1f1fgrSqHWbl-UE1YroshLgoouuxoCInDw_wcB.
So I had to get a little more creative...
I started calling around and leaving messages at aerospace CF manufacturers giving a quick explanation about my project and asking if they'd be willing to sell scraps or seconds. I started late on a weekend so didn't get ahold of anybody initially. Got on the line early on a Monday with someone on the east coast who sympathized but said they're only set up to sell to bigger customers (not surprising).
Eventually I landed on Pro Tech Composites. They're near me in Vancouver, WA, and sell a 1 lb. assortment pack of CF for $18.99: 12 Piece Assortment Sample Pack - Protech Composites and a 2 lb. box of seconds and scraps for $34.99.
I had a nice conversation with a sales rep who was very willing to try to work with me to get the best of whatever was available for larger sheets, which you'll see the results of in the pictures in an upcoming post.
As an aside, they have an option to order with or without adhesive. I wasn't sure which I wanted, so I opted to go simple and do it without. That meant as the project came together later, I was able to (or forced, depending on how you look at it), use double stick tape temporarily, followed by epoxy for a more permanent solution. If you're pretty sure you want to do this, you might think about just ordering with the adhesive pre-supplied. I'm not sure if it comes on the back of the CF or if it's in a sheet that you can apply to the CF yourself. Either way it might simplify things. If you try it, maybe call them up and ask how the strength compares to epoxy. Post back and let us know if you do!
Eventually I landed on Pro Tech Composites. They're near me in Vancouver, WA, and sell a 1 lb. assortment pack of CF for $18.99: 12 Piece Assortment Sample Pack - Protech Composites and a 2 lb. box of seconds and scraps for $34.99.
I had a nice conversation with a sales rep who was very willing to try to work with me to get the best of whatever was available for larger sheets, which you'll see the results of in the pictures in an upcoming post.
As an aside, they have an option to order with or without adhesive. I wasn't sure which I wanted, so I opted to go simple and do it without. That meant as the project came together later, I was able to (or forced, depending on how you look at it), use double stick tape temporarily, followed by epoxy for a more permanent solution. If you're pretty sure you want to do this, you might think about just ordering with the adhesive pre-supplied. I'm not sure if it comes on the back of the CF or if it's in a sheet that you can apply to the CF yourself. Either way it might simplify things. If you try it, maybe call them up and ask how the strength compares to epoxy. Post back and let us know if you do!
For the middle of the honeycomb, I was about ready to give up on nomex. Cardboard honeycomb seems like it could've been a great alternative, except even that was surprisingly hard to find for cheap and in less than 1" thickness. I also considered a thin sheet of aluminum or birch ply, with or without holes drilled in it a hexagonal pattern (would reduce weight, but I'm also lazy, so...).
I also ordered a cheap, shallow aluminum heat sink on eBay from China or Hong Kong. It's still not here. Oh well. It occurred to me that it might be hard to get the CF to stick to it anyway. For $5 or so, not a huge loss.
Anyway, I was bored one day and decided to go back to looking for nomex honeycomb, and found out it's available cheap... as a radiator protector for race cars! Honeycomb Radiator Protector, 19 x 26 Inch. $22 for 19 x 26 x 1.5".
Also available on Amazon Prime: https://www.amazon.com/Allstar-ALL3...&sr=8-1&keywords=honeycomb+radiator+protector
I also ordered a cheap, shallow aluminum heat sink on eBay from China or Hong Kong. It's still not here. Oh well. It occurred to me that it might be hard to get the CF to stick to it anyway. For $5 or so, not a huge loss.
Anyway, I was bored one day and decided to go back to looking for nomex honeycomb, and found out it's available cheap... as a radiator protector for race cars! Honeycomb Radiator Protector, 19 x 26 Inch. $22 for 19 x 26 x 1.5".
Also available on Amazon Prime: https://www.amazon.com/Allstar-ALL3...&sr=8-1&keywords=honeycomb+radiator+protector
The fun stuff: CONSTRUCTION!
The couple pounds of CF seconds from Pro Tech came in a variety of shapes and sizes, with a slight plurality around the size of a letter sheet of paper, maybe a little bigger. Those seemed like a good size to start with. That also turned out to be a good size to match the 19 x 26" radiator protector cut into quarters:
IIRC I had about 5 pieces of CF in the lot that were close to that size.
Next step after cutting them down: try a panel!
We used 2" or so wide double stick tape to start with, in case we had to modify the honeycomb sandwiches to make them sound decent.
It's amazing how much stiffer both the honeycomb and carbon fiber get when you sandwich them together, even with tape. Individually, in the sizes I got, you can bend them easily with just your fingers. Together and they feel like you could stand with both feet on top of them without crushing them. You will probably not bend them by hand no matter how much strength you apply.
Assembly by hand, careful to get them centered (although you can peel back up easily and without much risk of damaging anything, I think):
Attaching an exciter. Shown is the 40W Dayton Ultra: Dayton Audio DAEX32U-4 Ultra 32mm Exciter 40W 4 Ohm. The two bad reviews on PE refer to reliability issues. I haven't experienced that and may or may not be as mad as those respondents if I do. For now though, the audio quality is excellent.
I think we initially started with the 3M VHB backing that came on the exciter. This stuff is so strong though that for purposes of trying this out we thought it'd be better to peel it off and replace with weaker generic double stick tape. Even that still requires something like a putty knife to wedge the foot of the exciter off if you want to remove it, especially if it's been left sit a while. DEFINITELY use a tool to pry your exciter loose if you need to. Otherwise you're pulling directly on the voice coil and seeing whether that or the adhesive breaks loose first.
Demo material:
Track 5, "The Sinister Minister", has a great mix of highs and lows, dynamics and ambience that ought to make it entertaining, useful and most of all a FUNKY way to break these muthas in: https://www.youtube.com/watch?v=vPT3CGe4FS0
The couple pounds of CF seconds from Pro Tech came in a variety of shapes and sizes, with a slight plurality around the size of a letter sheet of paper, maybe a little bigger. Those seemed like a good size to start with. That also turned out to be a good size to match the 19 x 26" radiator protector cut into quarters:
An externally hosted image should be here but it was not working when we last tested it.
IIRC I had about 5 pieces of CF in the lot that were close to that size.
Next step after cutting them down: try a panel!
An externally hosted image should be here but it was not working when we last tested it.
We used 2" or so wide double stick tape to start with, in case we had to modify the honeycomb sandwiches to make them sound decent.
It's amazing how much stiffer both the honeycomb and carbon fiber get when you sandwich them together, even with tape. Individually, in the sizes I got, you can bend them easily with just your fingers. Together and they feel like you could stand with both feet on top of them without crushing them. You will probably not bend them by hand no matter how much strength you apply.
Assembly by hand, careful to get them centered (although you can peel back up easily and without much risk of damaging anything, I think):
An externally hosted image should be here but it was not working when we last tested it.
Attaching an exciter. Shown is the 40W Dayton Ultra: Dayton Audio DAEX32U-4 Ultra 32mm Exciter 40W 4 Ohm. The two bad reviews on PE refer to reliability issues. I haven't experienced that and may or may not be as mad as those respondents if I do. For now though, the audio quality is excellent.
An externally hosted image should be here but it was not working when we last tested it.
I think we initially started with the 3M VHB backing that came on the exciter. This stuff is so strong though that for purposes of trying this out we thought it'd be better to peel it off and replace with weaker generic double stick tape. Even that still requires something like a putty knife to wedge the foot of the exciter off if you want to remove it, especially if it's been left sit a while. DEFINITELY use a tool to pry your exciter loose if you need to. Otherwise you're pulling directly on the voice coil and seeing whether that or the adhesive breaks loose first.
Demo material:
An externally hosted image should be here but it was not working when we last tested it.
Track 5, "The Sinister Minister", has a great mix of highs and lows, dynamics and ambience that ought to make it entertaining, useful and most of all a FUNKY way to break these muthas in: https://www.youtube.com/watch?v=vPT3CGe4FS0
Last edited:
Is inline image posting broken? I only see a spinning "LOADING" icon in Firefox. You can right click and open in a new tab to view the imgur gallery though: Carbon fiber + nomex honeycomb sandwich DML panel construction - Album on Imgur. Those are in whatever order my phone put them in though, not the order that reflects how the project actually went.
Alternative arrangements: bracing and bass response
It's been well documented through both DIY experimentation and theory that DML panel frequency response is highly sensitive to how the panels are held or braced. Suspending them from a string on the back of the exciter sounds different from pinching an edge with a finger, which also sounds different from holding the long or short edges in your hands, which is different in turn from getting a second set of hands and pinching each corner.
For the theory, IIRC, there was someone from Europe - Sweden, Netherlands...? who published a thesis about DMLs that had some illustrations of modal wave numbers along with which areas of the panel would be vibrating relative to each other. There was some distinctive behavior he documented at lower numbered modes where only the four corners would vibrate, then only one pair of edges, then only the other two edges, before moving on to higher and more complex modes. I didn't completely follow the math but it looked as though maybe these lower, simpler modes involving edge vibration with a stationary middle of the panel happen at lower frequencies.
That certainly seemed like it could have been the case based on our experimentation.
The guy creeping into a couple of the pictures is my dad, whose shop this took place in. He's a violin bow maker, which I have to thank for access to tons of extra materials and adhesives. Both he and my mom are almost as into playing with this kind of vaguely sciency free form experimentation as I am.
Anyway, not pictured: if you've got three sets of hands like us, you may find that you're in a position to do something about excess panel edge excursion when you crank the bass up. We found that if you just set the panel on its edge, or hold it between a pinched finger and thumb, it vibrates way too violently and maybe starts to sound kind of like a rhythmic sequence of farts. Funnier than it has any right to be, but not really hi-fi. Next we tried two of us holding the panel stiffly at the four corners. This resulted in a substantial improvement in sound. We had no means to measure on hand, so we don't know for sure that we didn't just cut enough of the bass out entirely to make it sound better by not distorting, but it sure seemed like we were still hearing something just without the excess flapping around and possible CF self-noise. Next step after that was to get the third set of hands involved, so we're gripping the four corners, plus the middle of each of the long edges. That seemed to result in the best sound.
That inspired the image you see just above in this post (I hope). It's the fully built panel with a piece of 3/8" or so thick weather stripping stuck along each of the long edges. That weather stripping is clamped down with a bit of play between the jaws of two hand screw clamps. We used hand screw clamps both because they provide a nice solid parallel surface, and because they seemed like they were probably heavy enough to provide good backing for the damping without us having to hold onto them.
A quirk of our experimental apparatus: I sized my panels to what I thought would be about right to be powered by one Dayton 40W exciter each, but here you see two exciters attached. That's because our audio source was an old Sony integrated 5.1 receiver found at Goodwill for the princely sum of $12.99 (sticker probably still visible). That receiver didn't have a way we could find to turn off the subwoofer output and send full spectrum sound through the front left and front right channels. Based on some of the papers I've read at Tech Doc Library, I suspect that without some extensive modeling and experimentation, we'd probably get better sound out of a single exciter provided that it's powerful enough to drive the panel as hard as we're asking it to. Even so, this setup sounded really, really good. I'm planning to use something like that weather stripping holding the DML panels gently in picture frames as a more semi-permanent fixture.
An externally hosted image should be here but it was not working when we last tested it.
It's been well documented through both DIY experimentation and theory that DML panel frequency response is highly sensitive to how the panels are held or braced. Suspending them from a string on the back of the exciter sounds different from pinching an edge with a finger, which also sounds different from holding the long or short edges in your hands, which is different in turn from getting a second set of hands and pinching each corner.
For the theory, IIRC, there was someone from Europe - Sweden, Netherlands...? who published a thesis about DMLs that had some illustrations of modal wave numbers along with which areas of the panel would be vibrating relative to each other. There was some distinctive behavior he documented at lower numbered modes where only the four corners would vibrate, then only one pair of edges, then only the other two edges, before moving on to higher and more complex modes. I didn't completely follow the math but it looked as though maybe these lower, simpler modes involving edge vibration with a stationary middle of the panel happen at lower frequencies.
That certainly seemed like it could have been the case based on our experimentation.
The guy creeping into a couple of the pictures is my dad, whose shop this took place in. He's a violin bow maker, which I have to thank for access to tons of extra materials and adhesives. Both he and my mom are almost as into playing with this kind of vaguely sciency free form experimentation as I am.
Anyway, not pictured: if you've got three sets of hands like us, you may find that you're in a position to do something about excess panel edge excursion when you crank the bass up. We found that if you just set the panel on its edge, or hold it between a pinched finger and thumb, it vibrates way too violently and maybe starts to sound kind of like a rhythmic sequence of farts. Funnier than it has any right to be, but not really hi-fi. Next we tried two of us holding the panel stiffly at the four corners. This resulted in a substantial improvement in sound. We had no means to measure on hand, so we don't know for sure that we didn't just cut enough of the bass out entirely to make it sound better by not distorting, but it sure seemed like we were still hearing something just without the excess flapping around and possible CF self-noise. Next step after that was to get the third set of hands involved, so we're gripping the four corners, plus the middle of each of the long edges. That seemed to result in the best sound.
That inspired the image you see just above in this post (I hope). It's the fully built panel with a piece of 3/8" or so thick weather stripping stuck along each of the long edges. That weather stripping is clamped down with a bit of play between the jaws of two hand screw clamps. We used hand screw clamps both because they provide a nice solid parallel surface, and because they seemed like they were probably heavy enough to provide good backing for the damping without us having to hold onto them.
A quirk of our experimental apparatus: I sized my panels to what I thought would be about right to be powered by one Dayton 40W exciter each, but here you see two exciters attached. That's because our audio source was an old Sony integrated 5.1 receiver found at Goodwill for the princely sum of $12.99 (sticker probably still visible). That receiver didn't have a way we could find to turn off the subwoofer output and send full spectrum sound through the front left and front right channels. Based on some of the papers I've read at Tech Doc Library, I suspect that without some extensive modeling and experimentation, we'd probably get better sound out of a single exciter provided that it's powerful enough to drive the panel as hard as we're asking it to. Even so, this setup sounded really, really good. I'm planning to use something like that weather stripping holding the DML panels gently in picture frames as a more semi-permanent fixture.
Subjective results
Clarity and soundstage are excellent. Just like everyone else in the hundred pager megathread though, I've found that they are different and that after a while I think I like them.
I think I mentioned earlier that we don't have much in the way of measurement tools on hand. They do seem to make for some kind of a sense of distance between the listener and stuff that's often more in the foreground of recordings like vocals. I don't know how much of that is down to the soundstage, vs. maybe a frequency response problem that could be corrected by EQ, or coloration inherent to the construction method or particular to the dimensions and driver placement (slightly off center on both axes, as recommended).
Another possibility is that the bi- or omni-directional nature of the speakers is leading to weird reverbs from the back side sound radiation. The panels are currently playing on my desk where they sit in front of my Monitor Audio Silver 3i's (if that tells you anything about what I think of their sound quality). They seem to improve from that position if I stuff a throw pillow in between them and what's behind them. Sorry Monitor. It doesn't totally eliminate the effect... but then again I'm not sure it's unpleasant.
I do have a measurement mic buried in my desk somewhere. That will have to wait for a more permanent fixture though. When I get them framed with weather stripping damping, hung on the wall, and hooked up to a Behringer digital EQ, I'll see what I can do. That may be a month or more out.
Clarity and soundstage are excellent. Just like everyone else in the hundred pager megathread though, I've found that they are different and that after a while I think I like them.
I think I mentioned earlier that we don't have much in the way of measurement tools on hand. They do seem to make for some kind of a sense of distance between the listener and stuff that's often more in the foreground of recordings like vocals. I don't know how much of that is down to the soundstage, vs. maybe a frequency response problem that could be corrected by EQ, or coloration inherent to the construction method or particular to the dimensions and driver placement (slightly off center on both axes, as recommended).
Another possibility is that the bi- or omni-directional nature of the speakers is leading to weird reverbs from the back side sound radiation. The panels are currently playing on my desk where they sit in front of my Monitor Audio Silver 3i's (if that tells you anything about what I think of their sound quality). They seem to improve from that position if I stuff a throw pillow in between them and what's behind them. Sorry Monitor. It doesn't totally eliminate the effect... but then again I'm not sure it's unpleasant.
I do have a measurement mic buried in my desk somewhere. That will have to wait for a more permanent fixture though. When I get them framed with weather stripping damping, hung on the wall, and hooked up to a Behringer digital EQ, I'll see what I can do. That may be a month or more out.
Replacing double stick tape with epoxy for more permanent construction
The double stick tape version of the panel sounded decent, but knowing that, I wanted to go with something more permanent that also had a chance of sounding better: epoxy. We went with 5-minute dry, I think polyester based but I'm not sure. The QuickCure stuff we show here was just what we happened to have around. It doesn't seem to be the cheapest but I'm not at all sure it matters.
Our gluing jig:
On a flat surface, grab two sections of 2 x 4 or something of about that stability and height. Place a flat board on top wide enough to fit your DML panel. The 2 x 4s create space beneath the workspace so that when you've got the sandwich together, you can get clamps on without having to pick the whole sandwich + clamp apparatus up and fool around with it - the clamps fit underneath.
Put down a sheet of wax paper to catch any stray epoxy.
Mix the epoxy in a small container. We found that about 1 fl. oz. total of epoxy + binder was just about the right amount to cover one sheet of CF.
To the side of the jig, put down two more sheets of wax paper, one for each of the CF faces.
Spreading the epoxy:
Be sure to use gloves. Use a popsicle stick or something similar to lay down your mixed epoxy + binder, and spread with a fiberglass spreader as shown (I gather they're available at hardware stores. We just happened to have a few around. Thanks again dad!).
On our first go around, we just ended up doing a single face at a time because we only mixed up enough epoxy for that one. The single face, plus wet epoxy, plus honeycomb seems to be plenty strong enough to safely clamp in a jig:
You can see we put down a second sheet of wax paper on top of the facing. Next comes as flat of a block of wood as we can find, and six clamps to go along the edges, seen here on edge:
Leave sit to dry for 5ish minutes. You'll probably have some left over epoxy on the fiberglass spreaders. You can flex the fiberglass spreaders around and see how the epoxy responds to get a sense of how dry the stuff in the jig might be before you decide to disassemble it.
If you mix up 2 fl. oz. of epoxy at a time for panels of roughly the size we did, there's probably no reason to do a single face at a time. On the second panel, we did both faces at the same time from a single batch of epoxy, halving the drying time, and it seemed to work out great.
The double stick tape version of the panel sounded decent, but knowing that, I wanted to go with something more permanent that also had a chance of sounding better: epoxy. We went with 5-minute dry, I think polyester based but I'm not sure. The QuickCure stuff we show here was just what we happened to have around. It doesn't seem to be the cheapest but I'm not at all sure it matters.
An externally hosted image should be here but it was not working when we last tested it.
Our gluing jig:
An externally hosted image should be here but it was not working when we last tested it.
On a flat surface, grab two sections of 2 x 4 or something of about that stability and height. Place a flat board on top wide enough to fit your DML panel. The 2 x 4s create space beneath the workspace so that when you've got the sandwich together, you can get clamps on without having to pick the whole sandwich + clamp apparatus up and fool around with it - the clamps fit underneath.
Put down a sheet of wax paper to catch any stray epoxy.
Mix the epoxy in a small container. We found that about 1 fl. oz. total of epoxy + binder was just about the right amount to cover one sheet of CF.
To the side of the jig, put down two more sheets of wax paper, one for each of the CF faces.
An externally hosted image should be here but it was not working when we last tested it.
Spreading the epoxy:
An externally hosted image should be here but it was not working when we last tested it.
Be sure to use gloves. Use a popsicle stick or something similar to lay down your mixed epoxy + binder, and spread with a fiberglass spreader as shown (I gather they're available at hardware stores. We just happened to have a few around. Thanks again dad!).
On our first go around, we just ended up doing a single face at a time because we only mixed up enough epoxy for that one. The single face, plus wet epoxy, plus honeycomb seems to be plenty strong enough to safely clamp in a jig:
An externally hosted image should be here but it was not working when we last tested it.
You can see we put down a second sheet of wax paper on top of the facing. Next comes as flat of a block of wood as we can find, and six clamps to go along the edges, seen here on edge:
An externally hosted image should be here but it was not working when we last tested it.
Leave sit to dry for 5ish minutes. You'll probably have some left over epoxy on the fiberglass spreaders. You can flex the fiberglass spreaders around and see how the epoxy responds to get a sense of how dry the stuff in the jig might be before you decide to disassemble it.
If you mix up 2 fl. oz. of epoxy at a time for panels of roughly the size we did, there's probably no reason to do a single face at a time. On the second panel, we did both faces at the same time from a single batch of epoxy, halving the drying time, and it seemed to work out great.
Straight link to album: Carbon fiber + nomex honeycomb sandwich DML panel construction - Album on Imgur. They're not all annotated. I hope it's easy enough to track which ones go with which parts of the posts. Does right click -> "Open in new tab" work?
Last edited:
I doubt electrostatic drive would work. If you're going for the DML principle, which will presumably vibrate the panel in a different pattern than ESL drive, you're probably going to need a driver capable of moving some mass. At reasonable playback volume for just me sitting in my living room, I can lightly grasp them between thumb and forefinger and feel a fair amount of vibration 6 inches or more away from where the exciter is placed.
Weight per square foot is going to be in the ballpark of https://dragonplate.com/ecart/categories.asp?cID=111, probably with a gram or two extra for our less than precision epoxying process. Someone on the diysound subreddit pointed out that using a vacuum chamber can improve the quality of carbon fiber epoxy jobs. That might be a good addition to the process I've described here for people who could swing it. They certainly work and from what my ears can tell work well without it though.
Weight per square foot is going to be in the ballpark of https://dragonplate.com/ecart/categories.asp?cID=111, probably with a gram or two extra for our less than precision epoxying process. Someone on the diysound subreddit pointed out that using a vacuum chamber can improve the quality of carbon fiber epoxy jobs. That might be a good addition to the process I've described here for people who could swing it. They certainly work and from what my ears can tell work well without it though.
After digging around more, it's hard to find the density from that page, but ~1/2" thick honeycomb with carbon fiber facing is going to be around half a pound per square foot.
For comparison, Gatorfoam Technical Bulletin gives Gatorboard's density as 15 lb/ft^3, so maybe just a hair more. On that measure, these panels may not perform substantially better than various stiff foam boards for applications like ESL.
The honeycomb sandwiches ought to perform way better in terms of stiffness, though. https://www.lairdplastics.com/product/brands/gatorfoam/421-gator-gatorfoam-technical-datasheet reports Gatorboard's elastic modulus as between 5 and 15 N/mm^2 while Young's Modulus is a Measure of Stiffness in Carbon Fibre reports carbon fiber reinforced plastic - which I would guess is weaker than carbon + honeycomb - as 181 N/mm^2, more than 10 times as stiff, if my math is right.
For comparison, Gatorfoam Technical Bulletin gives Gatorboard's density as 15 lb/ft^3, so maybe just a hair more. On that measure, these panels may not perform substantially better than various stiff foam boards for applications like ESL.
The honeycomb sandwiches ought to perform way better in terms of stiffness, though. https://www.lairdplastics.com/product/brands/gatorfoam/421-gator-gatorfoam-technical-datasheet reports Gatorboard's elastic modulus as between 5 and 15 N/mm^2 while Young's Modulus is a Measure of Stiffness in Carbon Fibre reports carbon fiber reinforced plastic - which I would guess is weaker than carbon + honeycomb - as 181 N/mm^2, more than 10 times as stiff, if my math is right.
Anecdotally, these things feel strong as hell. I don't think I can bend them by hand - at all. Even though individually, both the honeycomb and the carbon fiber facings are very flexible. The panels feel like I could stand straight on them without damaging them, although I like the sound too much to risk trying it
For hobbyists, like us, the best source for great carbon fiber, IMO, is Soller Composites--
http://www.sollercomposites.com,carbon fiber,carbon fiber sleeve,Kevlar sleeve, fiberglass sleeves,carbon fiber fabric,epoxy,west system epoxy,nitrile,gloves,nitrile gloves,aramid,fiberglass,kevlar,tape,biaxial tape, biaxial sleeve
I built my own bicycle frame using their CF. Highest quality for great prices. They also sell epoxy suitable for laminating (that's what its called in the industry). Helpful tutorials, etc.
If you do not want to vacuum bag, then clamping is essential for a lightweight finished product.
http://www.sollercomposites.com,carbon fiber,carbon fiber sleeve,Kevlar sleeve, fiberglass sleeves,carbon fiber fabric,epoxy,west system epoxy,nitrile,gloves,nitrile gloves,aramid,fiberglass,kevlar,tape,biaxial tape, biaxial sleeve
I built my own bicycle frame using their CF. Highest quality for great prices. They also sell epoxy suitable for laminating (that's what its called in the industry). Helpful tutorials, etc.
If you do not want to vacuum bag, then clamping is essential for a lightweight finished product.
Yeah, that looks like a pretty killer deal. I went with Pro Tech for the simplicity of pre-stiffened sheets, but having slapped them together it doesn't seem like it would be a huge amount more work to use tape or fabric and paint some epoxy over it. Was it?
Also, got some documentation about that bike project? I thought about doing something like that a long time ago and never quite found the right path into it. Might be fun to get back to some day.
Also, got some documentation about that bike project? I thought about doing something like that a long time ago and never quite found the right path into it. Might be fun to get back to some day.
Without grasping all the implications, it just seems to me that ESL motivation is better off with a stiff radiating surface than a piece of Saran-wrap (allowing for differences in weight, thickness, etc.)???
With a film membrane, you do need to manage the location of the charge on the film, for example, and that wouldn't be much concern with a stiff surface that would average irregularities. On the other hand, not much attention needed to resonances with a film but could be troublesome with a stiff panel.
Still wondering....
BTW, I still don't have a good sense of how the stiff board compares in weight to Saran-wrap.
Ben
